Door Boot Seal
$240.70
In Stock
Fix Number: FIX1766023
Manufacturer #: WH08X10036
Manufactured by:
GE
-
Product Description
Also known as Bellow. The part may differ in appearance but functions same as original.
-
Works with the following brandsGeneral Electric
-
Works with the following productsWasher
-
Fixes the following symptomsLeaking, Burning smell
-
Part Number Cross ReferencePart# WH08X10036 replaces these:AP4334050, 1394050, WH08X10022, WH08X10040
Product Description
Also known as Bellow. The part may differ in appearance but functions same as original.
-
Works with the following brands:General Electric
-
Works with the following products:Washer
-
Fixes the following symptoms:Leaking, Burning smell
-
Part# WH08X10036 replaces these:AP4334050, 1394050, WH08X10022, WH08X10040
Videos For installing this part.
Replacing your Door Boot Seal

Questions and Answers
We're sorry, but our Q&A experts are temporarily unavailable.
Please check back later if you still haven't found the answer you need.
Installation Instructions Provided by Fix customers like you.
- < Prev
- 1
- Next >
Sort by:
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Sorry, we couldn't find any existing installation instruction that matched.
-
Customer:Harold from queens, NY
-
Parts Used:WH08X10036
-
Difficulty Level:Really Easy
-
Total Repair Time:30 - 60 mins
-
Tools:Pliers, Screw drivers
water leak through door
Repair was done as per your instructions. Problem i encounter was slipping the wire ring over the booth, I used a wet rag and moisten the booth all around. The wire ring slipped over very easy.
Was this instruction helpful to you?
Thank you for voting!
-
Customer:Christy from Council Bluffs, IA
-
Parts Used:WH08X10036
-
Difficulty Level:A Bit Difficult
-
Total Repair Time:More than 2 hours
-
Tools:Nutdriver, Pliers, Screw drivers, Socket set, Wrench (Adjustable), Wrench set
Removing and reattaching the metal band was diffiult because of the difficult access to the screw.
He did the repair watching the video. It was very helpful except there was a step that was not included. But he was able to figure it out.
Was this instruction helpful to you?
Thank you for voting!
-
Customer:Mark from Stanville, IL
-
Parts Used:WH08X10036
-
Difficulty Level:Really Easy
-
Total Repair Time:1- 2 hours
-
Tools:Pliers, Screw drivers, Socket set, Wrench set
Door boot seal then found I needed a water inlet pipe.
The day befor the parts came in I watched the self video and followed the instructions step by step and it was very easy to take washer apart, when the parts came in two days after I ordered them, reassembly was a breeze and the washer works well no more leaks, made me feel very proud of myself for doing it and thanks for the video, very hepful.
Was this instruction helpful to you?
Thank you for voting!
-
Customer:Gregory from Bellingham, WA
-
Parts Used:WH08X10036
-
Difficulty Level:A Bit Difficult
-
Total Repair Time:More than 2 hours
-
Tools:Nutdriver, Pliers, Screw drivers
Door boot seal was leaking
I simply followed the video which accompanied the part description . . . .took some time, but it was worth it.
Was this instruction helpful to you?
Thank you for voting!
-
Customer:Azalia from Johns Creek, GA
-
Parts Used:WH08X10036
-
Difficulty Level:Difficult
-
Total Repair Time:More than 2 hours
-
Tools:Pliers, Screw drivers, Socket set, Wrench (Adjustable)
leaking door boot seal
The hardest problem we had was replacing the boot seal back on the rim of the washer and the tightening the first band. The video was great to view as we were installing the part.
Was this instruction helpful to you?
Thank you for voting!
-
Customer:David from Jonesboro, AR
-
Parts Used:WH08X10036
-
Difficulty Level:Easy
-
Total Repair Time:30 - 60 mins
-
Tools:Nutdriver, Pliers, Screw drivers
Leaking down the front of the washer door
The most useful instruction I would make is to spend the preparation time to view and UNDERSTAND the video which is extremely helpful and well done. This is model specific and will allow you to take off the old gasket and place in the new without difficulty. Have the video handy and if a question arises simply go back and watch that step again. No other tools are required. (nut driver 7 mm could be replaced by a 7mm socket set but an extension bar would be helpful). Only other tip is related to removal and replacement of the inter door wire clamp. Be sure to loosen it sufficiently to remove easily and don't be surprised if it doesn't tighten all the way back to the original point, but be sure no kinks are in the washer and that it is tight when done. If you feel the least bit mechanically inclined with the video you can do it!
Was this instruction helpful to you?
Thank you for voting!
- < Prev
- 1
- Next >
