11755733-1-M-Whirlpool-WPW10503278-Electronic Control Board
Part Location Diagram of WPW10503278 Whirlpool Electronic Control Board
See part 8 in the diagram
Replacing your Whirlpool Refrigerator Electronic Control Board
11755733-1-S-Whirlpool-WPW10503278-Electronic Control Board 360 view
( Grid squares measure 1x1 inch )
11755733-1-S-Whirlpool-WPW10503278-Electronic Control Board 11755733-1-S-Whirlpool-WPW10503278-Electronic Control Board 360 view
Part Location Diagram of WPW10503278 Whirlpool Electronic Control Board Replacing your Whirlpool Refrigerator Electronic Control Board

Electronic Control Board

★★★★★
★★★★★
1 Review

Rated by 1 customers

?

Easy

15 - 30 mins

Ratings submitted by customers like you who bought this part.

?
$202.16
In Stock
Fix Number: FIX11755733
Manufacturer #: WPW10503278
Manufactured by: Whirlpool
  • Product Description

    This board will need to be programmed upon installation. The electronic control board is used in refrigerators to monitor and manage the temperature settings, such as cooling or defrosting times. If your fridge or freezer is too warm, too cold, is not defrosting, will not start, and/or runs too long then replacing the control board could solve your appliance problem. The tools needed for this installation project is a small flat blade screwdriver. *Please note: the board will need to be programmed after installation. Remember to unplug refrigerator from power source as a safety precaution. Refer to the manual provided by the manufacturer for further installation instructions and accurate guidance.

  • Works with the following brands
    Whirlpool, Maytag, Amana, Kenmore
  • Works with the following products
    Refrigerator
  • Fixes the following symptoms
    Fridge too warm, Freezer not defrosting, Will Not Start, Freezer too cold
  • Part Number Cross Reference
    Part# WPW10503278 replaces these:
    AP6022400, 12002339, 12002445, 12002449, 12002508, 12002509, 12002567, 12002706, 12784415, 12784415V, 12868502, 12868510, 12868513, 67003867, 67004453, 67004496, 67004907, 67005043, 67005280, 67005281 ... Show more , 67006034, 67006209, 67006214, 67006216, 67006226, 67006712, 67006740, 8208187, W10165748, W10503278 Show less
1 Installation Video 1 Question and Answer
1 Installation Instruction
1 Customer Review Model Compatibility
Product Description Part Videos Questions and Answers Installation Instructions Customer Reviews Model Compatibility

Product Description

This board will need to be programmed upon installation. The electronic control board is used in refrigerators to monitor and manage the temperature settings, such as cooling or defrosting times. If your fridge or freezer is too warm, too cold, is not defrosting, will not start, and/or runs too long then replacing the control board could solve your appliance problem. The tools needed for this installation project is a small flat blade screwdriver. *Please note: the board will need to be programmed after installation. Remember to unplug refrigerator from power source as a safety precaution. Refer to the manual provided by the manufacturer for further installation instructions and accurate guidance.

  • Works with the following brands:
    Whirlpool, Maytag, Amana, Kenmore
  • Works with the following products:
    Refrigerator
  • Fixes the following symptoms:
    Fridge too warm, Freezer not defrosting, Will Not Start, Freezer too cold
  • Part# WPW10503278 replaces these:
    AP6022400, 12002339, 12002445, 12002449, 12002508, 12002509 ... Show more , 12002567, 12002706, 12784415, 12784415V, 12868502, 12868510, 12868513, 67003867, 67004453, 67004496, 67004907, 67005043, 67005280, 67005281, 67006034, 67006209, 67006214, 67006216, 67006226, 67006712, 67006740, 8208187, W10165748, W10503278 Show less

Videos For installing this part.

Replacing your Electronic Control Board

Replacing your Electronic Control Board

Questions and Answers

We're sorry, but our Q&A experts are temporarily unavailable.
Please check back later if you still haven't found the answer you need.

1 question answered by our experts.
  • 1
Sort by:
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Sorry, we couldn't find any existing answers that matched.
Try using some different or simpler keywords, or submit your new question by using the "Ask a Question" button above!
Jill
August 28, 2022
Fridge not cooling Freezer works,
For model number Mff2558fez01
Hey Jill, thank you for your question. If your fridge is not cooling then we recommend you change its electronic control board, part number FIX11755733. We hope this helps. If you need help placing an order, customer service is open 7 days a week. Thanks again for your great question.

Was this helpful?
Thank you for voting!
  • 1

Installation Instructions Provided by Fix customers like you.

Average Repair Rating: 3.9 / 5.0, 1 reviews.
  • 1
Sort by:
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Sorry, we couldn't find any existing installation instruction that matched.
  • Customer:
    Jeff from Stamford, CT
  • Parts Used:
    WPW10503278
  • Difficulty Level:
    Easy
  • Total Repair Time:
    15 - 30 mins
  • Tools:
    Screw drivers
warm refrigerator, cold freezer (w/ice buildup blocking the ducts on the back freezer wall)
I had had this problem when the refrigerator was about 3 years old. At that time, Amana replaced the control board for free under our extended warranty. They may have also replaced the thermistor, but I'm not sure about that. When the problem occurred again a few weeks ago, everything I read seemed to suggest that the problem was most likely a failure (again) of the control board. I was able to track down a PDF of the service manual, which was invaluable in doing this repair, although I think that the replacement control board came with installation instructions. JUST MAKE SURE YOU UNPLUG THE FRIDGE OR TURN OFF THE CIRCUIT BREAKER BEFORE ATTEMPTING ANY REPAIR. The board is easy to access- it's located in a drop-down compartment next to the light in the refrigerator compartment. Be careful when pressing on the tabs that release the drop-down-panel- I found it helpful to use a mirror to be able to see where to press on the tabs. The old board came right out- it had 2 plugs and a few screws. The replacement board fit in perfectly. When I re-started the fridge, the new board had to be programmed, but the service manual had instructions for that- it was pretty easy. It's been about 3 weeks now and the refrigerator is running fine- no recurrence of the problem. ONE THING WORTH NOTING- I can't swear to it, but I think we might have had a brief power outage just before the problem with the warm refrigerator started. My house gets a lot of those voltage fluctuations. The control board is probably sensitive to electrical quality them same way a computer is. I am thinking of investing in a surge suppressor outlet where the fridge is plugged in to avoid having this happen again in the future.
14 of 14 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
  • 1
Back to Top
★ Customer Reviews
Average Rating: (1 Review)
5.0
★★★★★
★★★★★
Filter By Rating:
  • 5★
    1
  • 4★
    0
  • 3★
    0
  • 2★
    0
  • 1★
    0
  • 1
Sort by:
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Sorry, we couldn't find any existing reviews that matched. Try using some different or simpler keywords.
★★★★★
★★★★★
Judith A - October 11, 2020
Verified Purchase
Great Video Instruction
Replaced the part with no problems at all. Very good video and description on how to. Just a waiting game now to see if freezer vents freeze up again, generally takes a week or so to freeze back up which causes the refrigerator to get warm, no cold air flowing up i guess. This all started when power went out for 4 hours each day, 2 days in a row. If it doesn't work, guess i will try to replace the Thermistor next and hope that fixes the issues. Refrigerator is only 5 years old.
  • 1
Model Compatibility
This part works with the following models:
Fix Number: FIX11755733
Manufacturer Part Number: WPW10503278
Brand
Model Number
Description
Kenmore
10669312310
Refrigerator - REFRIGERATOR
Kenmore
596467934251
Refrigerator - REFRIGERATOR
Kenmore
596467934351
Refrigerator - REFRIGERATOR
Kenmore
596467934451
Refrigerator - REFRIGERATOR
Kenmore
596467934951
Refrigerator - REFRIGERATOR
Kenmore
59655652500
Refrigerator
Kenmore
59655653500
Refrigerator
Kenmore
59655654500
Refrigerator
Kenmore
59655659500
Refrigerator
Kenmore
59657012600
Refrigerator
Kenmore
59657013600
Refrigerator
Kenmore
59657016600
Refrigerator
Kenmore
59657019600
Refrigerator
Kenmore
59665232400
Refrigerator
Kenmore
59665232401
Refrigerator
Kenmore
59665232404
Refrigerator
Kenmore
59665234400
Refrigerator
Kenmore
59665234401
Refrigerator
Kenmore
59665234402
Refrigerator
Kenmore
59665234404
Refrigerator
Kenmore
59665239400
Refrigerator
Kenmore
59665239401
Refrigerator
Kenmore
59665239402
Refrigerator
Kenmore
59665239404
Refrigerator
Kenmore
59665239405
Refrigerator
Kenmore
59665332600
Refrigerator
Kenmore
59665332602
Refrigerator
Kenmore
59665333602
Refrigerator
Kenmore
59665339602
Refrigerator
Kenmore
59665932300
Refrigerator
