Water Inlet Valve Assembly
$123.82
In Stock
Fix Number: FIX3533117
Manufacturer #: AJU72992601
Manufactured by:
LG
-
Product Description
This includes the primary and secondary valves along with the wire harness.
-
Works with the following brandsLG, Kenmore
-
Works with the following productsRefrigerator, Freezer
-
Fixes the following symptomsLeaking, Not dispensing water, Ice maker not making ice
-
Part Number Cross ReferencePart# AJU72992601 replaces these:AP4671476, 5221JA2011J, 5221JA2011P, 6877JB3036V, AJU72992606, EAD61548201, EBD60664501
Product Description
This includes the primary and secondary valves along with the wire harness.
-
Works with the following brands:LG, Kenmore
-
Works with the following products:Refrigerator, Freezer
-
Fixes the following symptoms:Leaking, Not dispensing water, Ice maker not making ice
-
Part# AJU72992601 replaces these:AP4671476, 5221JA2011J, 5221JA2011P, 6877JB3036V, AJU72992606, EAD61548201 ... Show more , EBD60664501 Show less
Videos For installing this part.
Replacing your Water Inlet Valve Assembly
Questions and Answers
We're sorry, but our Q&A experts are temporarily unavailable.
Please check back later if you still haven't found the answer you need.
Installation Instructions Provided by Fix customers like you.
- < Prev
- 1
- Next >
Sort by:
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Sorry, we couldn't find any existing installation instruction that matched.
-
Customer:Robert from Bridgeport, WV
-
Parts Used:AJU72992601
-
Difficulty Level:Really Easy
-
Total Repair Time:30 - 60 mins
-
Tools:Screw drivers, Wrench set
Leaking connection from the valve to the Ice Maker line
Saw the leak, unplugged refrigerator, turned off water. Disconnected water line, removed back panel. Removed part and unplugged electrical connectors. Removed ice maker supply line, cut it about 2 feet ups and put a splicer/connector in. Replaced with a new line from there back to the valve. Inserted new tube in valve and made sure it was deep enough in and then secured it. (I replaced part of the line because it was not smoothed and that is where the leak was coming from). Reconnected the electrical connections and attached valve back to refrig. Put panel back on and then reconnected the water supply line. Turned water back on and checked for leaks. Plugged refrig back in and pushed back in place.
Was this instruction helpful to you?
Thank you for voting!
- < Prev
- 1
- Next >
★
Customer Reviews
Filter By Rating:
- < Prev
- 1
- Next >
Sort by:
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Sorry, we couldn't find any existing reviews that matched. Try using some different or simpler keywords.
Paul S - October 15, 2021
Verified Purchase
Exactly what I needed
Very good quality valve, fast shipping
- < Prev
- 1
- Next >
Model Compatibility
This part works with the following models:
Fix Number: FIX3533117
Manufacturer Part Number: AJU72992601
Manufacturer Part Number: AJU72992601
Brand
Model Number
Description
