MGR6600FW3 Admiral Range

I numbered every part. ex: 1 L., for first part removed left side. I used a magic marker to circle the holes and wrote the number of screws used on the part, set the srews in a separete place, so that I new where these screws went to. The cleanup was pretty time consuming, but I was able to keep my stove, when every repairman I called to ... Read more fix my stove told me I was better off buying a new stove. ($600.00 stove 2 years old)Please Note: The insulation blanket needed for the entire stove is two pieces, the sides and top are one part # and the bottom and back, are another part #. I did not know this. I just purchased the top and sides. I got lucky, the back and bottom were still in good shape. So I guess I should have read the description of the part more carefully to see what it covers, before I ordered it. It took two people two hours to do the work, it was really nice to have an extra set of eyes, to remember what direction pieces of metal from the stove went. I would do it all over in a heart beat instead of buying a new stove.

Bought a new house last fall. Jenn-Air range had two element cooktop with two element grill. Oven went out and while service man was here, I asked him to check on the price of another two heater element panel to replace the grill. He subsequently called to say the part I wanted was not available. I immediately got on the internet and ... Read more did a search. Found it "ships same day" for what I thought was a very reasonable price at PartSelect. Unplugged the grill and plugged in the cooking plate. We now have four usable "burners" instead of two. Thanks PartSelect!

After reading many forums found that this error happens when trying to clean the oven and there is a failure in the latch motor to lock the oven door. It was suggested 1st to just tunr the breaker off to the over wait and then turn it back on to see if the error would clear by itself. If not then you'll have to do what I did and buy a n ... Read more ew Latch Motor and replace it. Fairly easy to do:
) Move oven to get to the back panel
) Disconnect oven from power
) Remove the 8 screws to get the back panel off
) REmove the Latch motor screws (2) and remove the motor after twisting to get the latch rod off
) Put in new latch motor by 1st putting the latch rod in the motor assembly
) Screw the new motor in place
) Replace back panel
) Power on Oven
DONE!
