Watch the install video
11742544-1-M-Whirlpool-WP4449263-Range Inner Door Glass
Part Location Diagram of WP4449263 Whirlpool Range Inner Door Glass
See part 7 in the diagram
Replacing your KitchenAid Wall Oven Range Inner Door Glass
( Grid squares measure 1x1 inch )
11742544-1-S-Whirlpool-WP4449263-Range Inner Door Glass 11742544-2-S-Whirlpool-WP4449263-Range Inner Door Glass Part Location Diagram of WP4449263 Whirlpool Range Inner Door Glass Replacing your KitchenAid Wall Oven Range Inner Door Glass

Range Inner Door Glass WP4449263

Rated by 1 customers

?

A Bit Difficult

15 - 30 mins

Ratings submitted by customers like you who bought this part.

?
$97.14
In Stock
Fix Number:
FIX11742544
Manufacturer #:
WP4449263
Manufactured by:
Whirlpool

Jump to:

Product Description

Glass only.

  • Works with the following brands:
    KitchenAid, Whirlpool
  • Works with the following products:
    Wall Oven, Range, Microwave Oven Combo
  • Part# WP4449263 replaces these:
    AP6009385, 4449263
Works with the following brands:
KitchenAid, Whirlpool
Works with the following products
Wall Oven, Range, Microwave Oven Combo
Part Number Cross Reference
Part# WP4449263 replaces these:
AP6009385, 4449263

Videos For installing this part.

Replacing your Range Inner Door Glass

Replacing your Range Inner Door Glass

Questions and Answers

Be the first to ask our experts a question about this part!

Affresh Dishwasher Cleaner Tablets - 6
$21.89
In Stock
Part Number: FIX12345667
Affresh dishwasher Cleaner is specially formulated to help remove limescale and mineral build-up that can be unsightly and could affect your dishwasher's performance. Each tablet is designed to clean inside your machine ...
Affresh Washing Machine Cleaner - 3 pack
$19.89
In Stock
Part Number: FIX1960673
This washing machine cleaner includes three time-release tablets designed to remove odor-causing residues, grime, and buildup from high-efficiency and top-load washing machines. The tablets work by cleaning the tub, pump...
Produce Preserver Filter
$17.75
In Stock
Part Number: FIX3503014
Fresh Flow Produce Preserver is made for your refrigerator to help keep produce fresh for longer by absorbing the chemical, ethylene, that causes your fruits and vegetables to ripen quicker. Your produce could be fresh f...
Affresh Washing Machine Cleaner Tablets – 6 Count
$27.87
In Stock
Part Number: FIX12345661
This Affresh Washing Machine Cleaner deep cleans to help remove the odor-causing residues and grime that daily loads leave behind. The time-release tablets are EPA Safer Choice certified, septic-safe and designed to clea...
Refrigerator Deodorizer
$29.78
In Stock
Part Number: FIX12739141
Refrigerator deodorizers help to reduce bacteria growth and therefore reduce smells and extend the life of food.
Affresh Ice Machine Cleaner
$26.87
In Stock
Part Number: FIX12583750
This nickel-safe, unscented ice machine cleaner measures 16 fluid ounces and is used to remove mineral build-up and hard water and is compatible with several makes and models of freestanding ice machines. To use properly...

Installation Instructions Provided by Fix customers like you.

Average Repair Rating: 3.4 / 5.0, 1 reviews.
  • 1
Sort by:
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Sorry, we couldn't find any existing installation instruction that matched.
Customer:
Jeff from Brentwood, TN
Parts Used:
WP4449263
Difficulty Level:
A Bit Difficult
Total Repair Time:
15 - 30 mins
Tools:
Screw drivers
Broken Glass in wall mounted Kitchen Aid Oven - any of the inside 3 glasses (there are 4 in total)
Remove door - biggest trick of the process 1-Open the door 2- At each of the hinges there is a small clip that rotates on the same axis as the hinge. Rotate them both out towards the room 3- Close the door to about 6 inches from being fully closed. This is as far as it goes with the clips rotated. 4- lift the door, rotate it closed slig htly further and pull it straight away from the oven. 5- lay the oven door outside up on a work table covered with cardboard or towels. 6-Remove 2 screws and two clips they are holding from bottom of door. 7-Remove remaining screws from around perimeter and oven side of door 8- Slide front of door down 1/4 inch and remove from remainder of door. 9-Remove 2 screws from bottom and 3 from top of first glass frame pieces. All of the screws up to this point are the same, these screws are different, Keep them separate. 10- Remove the frame strip at the bottom of the glass (just the first one they are two deep) 11- slip the glass down out of the clips on the top corners and out. 12- Remove the second frame strip and slide the next glass down out of the retaining slots at the top 13- Remove the hinges, keep right an left separate, they are slightly different and the screws won't all go back in if they are mixed. 14- Remove the inner panel carefully so as not to tear the glass insulation unnecessarily. 15- The last glass should now lift out. 16- Clean all parts as desired, oven cleaner works well on the glass. 17-Reverse the procedure to put it back together replacing the broken glass. 18- Be careful to position the glass insulation back in carfully so that it does not show through the window. 19- Once back together (all screws used) hold the door nearly verticle and put the hinge arms back into the slots in the wall oven. 20-Open the door all the way and rotate the clips back toward the wall to lock the door on the oven.
Read less
0 of 1 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
  • 1

Model Compatibility

This part works with the following models:
Fix Number: FIX11742544
Manufacturer Part Number: WP4449263
Brand Model Number Description
Whirlpool GBD307NKB0 Range - Whirlpool Range/Stove/Oven Model GBD307NKB0 Parts
Whirlpool GBD307NKQ0 Range - Whirlpool Range/Stove/Oven Model GBD307NKQ0 Parts
Whirlpool GBD307PDB0 Wall Oven - Built-in, Wall, Electric 30"
Whirlpool GBD307PDB09 Wall Oven - Built-in, Electric
Whirlpool GBD307PDB1 Wall Oven - Built-in, Electric
Whirlpool GBD307PDB2 Wall Oven - Built-in, Electric
Whirlpool GBD307PDB3 Wall Oven - Built-in, Electric, Wall
Whirlpool GBD307PDB4 Wall Oven - Built-in, Electric
Whirlpool GBD307PDB5 Wall Oven - Built-in, Electric
Whirlpool GBD307PDB6 Wall Oven - Built-in, Electric
Whirlpool GBD307PDB7 Wall Oven - Built-in, Electric
Whirlpool GBD307PDQ0 Wall Oven - Built-in, Wall, Electric 30"
Whirlpool GBD307PDQ09 Wall Oven - Built-in, Electric
Whirlpool GBD307PDQ1 Wall Oven - Built-in, Electric
Whirlpool GBD307PDQ2 Wall Oven - Built-in, Electric
Whirlpool GBD307PDQ3 Wall Oven - Built-in, Electric, Wall
Whirlpool GBD307PDQ4 Wall Oven - Built-in, Electric
Whirlpool GBD307PDQ5 Wall Oven - Built-in, Electric
Whirlpool GBD307PDQ6 Wall Oven - Built-in, Electric
Whirlpool GBD307PDQ7 Wall Oven - Built-in, Electric
Whirlpool GBD307PDS09 Wall Oven - Built-in, Electric
Whirlpool GBD307PDS1 Wall Oven - Built-in, Electric
Whirlpool GBD307PDS2 Wall Oven - Built-in, Electric
Whirlpool GBD307PDS3 Wall Oven - Built-in, Electric, Wall
Whirlpool GBD307PDS4 Wall Oven - Built-in, Electric
Whirlpool GBD307PDS5 Wall Oven - Built-in, Electric
Whirlpool GBD307PDS6 Wall Oven - Built-in, Electric
Whirlpool GBD307PDS7 Wall Oven - Built-in, Electric
Whirlpool GBD307PDT09 Wall Oven - Built-in, Electric
Whirlpool GBD307PDT1 Range - Whirlpool Range/Stove/Oven Model GBD307PDT1 Parts
