Replacing your Whirlpool Refrigerator Compressor Start Relay

Compressor Start Relay

Rated by 6 customers

Very Easy

Less than 15 mins

Ratings submitted by customers like you who bought this part.

$94.66

Fix Number: FIX11740412

Manufacturer #: WP2319792

Manufactured by: Whirlpool

Product Description

NOTE: This part has been replaced by the manufacturer. It may look different from the original but will still function the same. This part is both the start relay and the overload. The start relay boosts the compressor, and then shuts off as soon as the motor gets up to speed and the overload provides extra protection against excessive temperatures.
Works with the following brands

Whirlpool, KitchenAid, Kenmore, Thermador
Works with the following products
Refrigerator, Freezer
Fixes the following symptoms

Will Not Start, Fridge too warm, Freezer section too warm, Fridge and Freezer are too warm
Part Number Cross Reference

Part# WP2319792 replaces these:

AP6007299, 2255198, 2319792

1 Installation Video

1 Related Part Questions and Answers

6 Installation Instructions Model Compatibility

Product Description Part Videos Questions and Answers Related Parts Installation Instructions Model Compatibility

Product Description

NOTE: This part has been replaced by the manufacturer. It may look different from the original but will still function the same. This part is both the start relay and the overload. The start relay boosts the compressor, and then shuts off as soon as the motor gets up to speed and the overload provides extra protection against excessive temperatures.

Works with the following brands:

Whirlpool, KitchenAid, Kenmore, Thermador
Works with the following products:
Refrigerator, Freezer
Fixes the following symptoms:

Will Not Start, Fridge too warm, Freezer section too warm, Fridge and Freezer are too warm
Part# WP2319792 replaces these:

AP6007299, 2255198, 2319792

Videos For installing this part.

Replacing your Compressor Start Relay

Replacing your Compressor Start Relay

Questions and Answers

Be the first to ask our experts a question about this part!

Related PartsAdditional or alternate parts to consider.

Installation Instructions Provided by Fix customers like you.

Average Repair Rating: 5.0 / 5.0, 6 reviews.

< Prev
1
Next >

Sort by:

Customer:

Michael from ODESSA, FL
Parts Used:
WPW10662129, WP2319792
Difficulty Level:
Really Easy
Total Repair Time:
15 - 30 mins
Tools:
Nutdriver

Freezer not defrosting correctly

We were hearing a clicking noise coming from our refrigerator/freezer combo. The freezer wasn’t defrosting correctly. I pulled the unit out, unplugged the refrigerator, pulled off the flimsy cardboard backing. I pulled off the old unit (compressor start relay/capacitor) unplugged it from the wiring harness, hooked up the new components to the unit and plugged it into to the compressor (three pins, only one way to put it on correctly) and put the cover back on. I plugged the unit back in and pushed it back into place and it has been working like a champ for a couple of weeks now

7 of 7 people found this instruction helpful.

Was this instruction helpful to you?

Customer:

David from Rancho Santa Margarita, CA
Parts Used:
WPW10662129, WP2319792
Difficulty Level:
Very Easy
Total Repair Time:
Less than 15 mins
Tools:
Nutdriver

Freezer stopped cooling. Got the "Click and Whirr."

I'm not a repairman, but fairly handy, so I looked around on the net, and saw the problem was probably the capacitor or the combo start device. Found a video on this site that was very clear. I ordered both parts just to be safe. Got 'em within a week and did the installation as described on the video(s). Super easy. She fired right up and is cooling as well as before! $95 for the parts and shipping saved a refrigerator freezer no longer made! Thank you!

3 of 3 people found this instruction helpful.

Was this instruction helpful to you?

Customer:

Lisa from Yulee, FL
Parts Used:
WP2319792
Difficulty Level:
Very Easy
Total Repair Time:
Less than 15 mins
Tools:

Both comparments very warm but fan working and lights on

Bought Capacitor, but I had to purchase Combo Start Up Kit that Cap goes into. The site said that 78% of the time my problem of both compartments being warm were resolved/repair by replacing Capacitor, but when the item was replaced it did not resolve and my son looked further and found that it would then be the Combination
Start Up Kit (Part# PS11740412), which starts the compressor.
Thanks ! https://youtube/Mrdal-7h2wU is the video used to install both parts. I was able to use my old Capacitor and I returned the new one that I purchased first for full refund minus shipping.

1 person found this instruction helpful.

Was this instruction helpful to you?

Customer:

Cegal A. from Haleyville, AL
Parts Used:
WP2319792
Difficulty Level:
Really Easy
Total Repair Time:
Less than 15 mins
Tools:
Nutdriver

FREEZER/FRIDGE WOULD NOT COOL COULD HEAR COMPRESSOR WOULD RUN FOR ABOUT 10 SECONDS THE STOP ABOUT A MINUTE LATER WOULD COME ON THEN GO OFF

`Need to unplug the appliance. Removed the screws that held the back lower cardboard cover on. After locating the compressor I took off the retaining spring that held the combination start device with capacitor onto the compressor. Then I unplugged a two wire clip, removed the capacitor and combination start device. T then placed the capacitor on the new part and plugged in the two wire clip. then I plugged the new part onto the compressor. The retaining spring could not be put back because the new part was not the same thickness as the old. Did not matter worse perfect now. It was a very easy repair.

0 of 1 people found this instruction helpful.

Was this instruction helpful to you?

Customer:

Bill from Midlothian, VA
Parts Used:
WP2319792
Difficulty Level:
Really Easy
Total Repair Time:
Less than 15 mins
Tools:
Nutdriver, Screw drivers

compressor runs for 5 to 10 seconds,cuts off, over and over again

unplug refrigerator, removed back cover ,then unplugged combination start device from compressor. unplug the wiring connector then plug new device and wiring to compressor

0 of 1 people found this instruction helpful.

Was this instruction helpful to you?

Customer:

Stephen from Warsaw, MO
Parts Used:
WPW10662129, WP2319792
Difficulty Level:
Very Easy
Total Repair Time:
Less than 15 mins
Tools:
Nutdriver, Pliers

Compressor would not stay running. Sounded like it was trying to start, then would go off in a few seconds

I did the repair exactly like the video showed. The instructions were step by step and it was super easy to do. Even with overnight shipping, we only spent $108 to fix the refrigerator. We figured we would spend at least that much just to have someone come and look at it and it sure beats buying a new $1400 refrigerator! I would recommend this site to everyone!!

0 of 1 people found this instruction helpful.

Was this instruction helpful to you?

< Prev
1
Next >

Model Compatibility

This part works with the following models:

Fix Number: FIX11740412
Manufacturer Part Number: WP2319792

Kenmore

10642102300

Freezer

Kenmore

10642102301

Freezer

Kenmore

10642104300

Freezer

Kenmore

10642106300

Freezer

Kenmore

10642106301

Freezer

Kenmore

10653352300

Refrigerator

Kenmore

10653354300

Refrigerator

Kenmore

10653359300

Refrigerator

Kenmore

10653362300

Refrigerator

Kenmore

10653364300

Refrigerator

Kenmore

10653369300

Refrigerator

Kenmore

10654602300

Refrigerator

Kenmore

10654603300

Refrigerator

Kenmore

10654604300

Refrigerator

Kenmore

10654606300

Refrigerator

Kenmore

10654609300

Refrigerator

Kenmore

10654612300

Refrigerator

Kenmore

10654613300

Refrigerator

Kenmore

10654614300

Refrigerator

Kenmore

10654616300

Refrigerator

Kenmore

10654619300

Refrigerator

Kenmore

10654682300

Refrigerator

Kenmore

10654683300

Refrigerator

Kenmore

10654684300

Refrigerator

Kenmore

10654689300

Refrigerator

Kenmore

10654692300

Refrigerator

Kenmore

10654693300

Refrigerator

Kenmore

10654694300

Refrigerator

Kenmore

10654699300

Refrigerator

Kenmore

10655522400

Refrigerator
