Refrigerator Pantry Drawer Door Cover
Works With Model AFD2535DEW!
$105.22
In Stock
Fix Number: FIX11723190
Manufacturer #: W10827015
Manufactured by:
Whirlpool
Works With Model AFD2535DEW!
-
Product Description
This genuine OEM part is a door cover for your refrigerator pantry drawer. It helps to maintain the proper temperature and humidity in the drawer by providing a seal when closed. Other names for this part include pantry drawer door or pantry drawer cover. No tools are required to replace this part. Simply release the locking tab and pull out the old cover one end at a time. Insert the new door cover, making sure the holes are properly secured around the hinge pins. The door cover should now open and close easily. To prevent damage to the new door cover, make sure that the snack drawer is fully pushed back into place before closing the cover, so that it can lay flat on the drawer.
-
Works with the following brandsMaytag, Whirlpool, Kenmore, Amana
-
Works with the following productsRefrigerator
-
Fixes the following symptomsDoor won’t open or close, Fridge too cold
-
Part Number Cross ReferencePart# W10827015 replaces these:AP5985816, 12656813, 12656814, 12656815, 12656816, 67002319, 67002812, 67003170, 67003305, 67003332, 67003333, 67004643, 67004698, 67005899, 67005900, 67005903, 67005910, 8171060, 8171122
Product Description
This genuine OEM part is a door cover for your refrigerator pantry drawer. It helps to maintain the proper temperature and humidity in the drawer by providing a seal when closed. Other names for this part include pantry drawer door or pantry drawer cover. No tools are required to replace this part. Simply release the locking tab and pull out the old cover one end at a time. Insert the new door cover, making sure the holes are properly secured around the hinge pins. The door cover should now open and close easily. To prevent damage to the new door cover, make sure that the snack drawer is fully pushed back into place before closing the cover, so that it can lay flat on the drawer.
-
Works with the following brands:Maytag, Whirlpool, Kenmore, Amana
-
Works with the following products:Refrigerator
-
Fixes the following symptoms:Door won’t open or close, Fridge too cold
-
Part# W10827015 replaces these:AP5985816, 12656813, 12656814, 12656815, 12656816, 67002319 ... Show more , 67002812, 67003170, 67003305, 67003332, 67003333, 67004643, 67004698, 67005899, 67005900, 67005903, 67005910, 8171060, 8171122 Show less
Videos For installing this part.
Replacing your Refrigerator Pantry Drawer Door Cover
Questions and Answers
We're sorry, but our Q&A experts are temporarily unavailable.
Please check back later if you still haven't found the answer you need.
Related PartsAdditional or alternate parts to consider.
Installation Instructions Provided by Fix customers like you.
- < Prev
- 1
- Next >
Sort by:
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Sorry, we couldn't find any existing installation instruction that matched.
-
Customer:Warren R . from Ottumwa, IA
-
Difficulty Level:Really Easy
-
Total Repair Time:15 - 30 mins
-
Tools:Nutdriver
endcap drawer lid pin broken and pantry drawer lid clear window (plastic) cracked
Removed old pantry drawer /and plastic lid and glass shelf above as well as the two slide in drawers above(for work room) Used nut driver to remove (2) screws on right side holding drawer slide and (2) screws holdin endcap. carefully removed the piece and worked it loose. It is connected to another piece at the end, just angle it out. Switched the plastic slide piece from old to new and reinstalled side piece with nut driver. Plastic pantry drawer lid put on at this time. Open and close and check for fit My pantry drawer lid seems to catch a little right in the middle when opening.
Was this instruction helpful to you?
Thank you for voting!
-
Customer:Adrian from SYLMAR, CA
-
Difficulty Level:Very Easy
-
Total Repair Time:Less than 15 mins
-
Tools:
Broken shelf trim . Missing chiller door/ broke pantry door broke/missing
No tools needed all by hand. Snaps in like original.
Was this instruction helpful to you?
Thank you for voting!
-
Customer:Tom from Memphis, TN
-
Parts Used:W10827015
-
Difficulty Level:Easy
-
Total Repair Time:Less than 15 mins
-
Tools:Nutdriver
Replace broken plastic pin
Followed Video recording
Was this instruction helpful to you?
Thank you for voting!
-
Customer:Ned from Orlando, FL
-
Parts Used:W10827015
-
Difficulty Level:Very Easy
-
Total Repair Time:Less than 15 mins
-
Tools:
Plexiglass in the cover was broken from a glass bottle falling on it.
The tabs on the cover that go over the hinges are flexible and a gentle push of the cover to the left allowed for the right tab to come off the hinge and then slide the cover right to pull off the left hinge. The new cover slid in just as easily.
Was this instruction helpful to you?
Thank you for voting!
-
Customer:Tony from Hopland, CA
-
Difficulty Level:Very Easy
-
Total Repair Time:Less than 15 mins
-
Tools:
Broken drawer support and Lower clear pantry door cover
I reviewed the exceptional installation Fix.com videos prior to purchase which gave me high confidence to order. Fast quality shipping got the parts to me quickly and it took about five minutes to install both.
The family said that it looked like a new refrigerator. Thank you Fix.com!
The family said that it looked like a new refrigerator. Thank you Fix.com!
Was this instruction helpful to you?
Thank you for voting!
-
Customer:Grace from Huntington Beach, CA
-
Parts Used:W10827015
-
Difficulty Level:A Bit Difficult
-
Total Repair Time:15 - 30 mins
-
Tools:Screw drivers
Needed to install a new deli drawer
I finally got the new drawer in -not easy and I ended up with n extra piece . It is a long white strip. Maybe if I took the drawer back out, I would see where the piece belongs.However, since I had such a difficult time getting the drawer back in, I did not want to take it out again. I was afraid of breaking something. The drawer seems to work fine without the piece.
Was this instruction helpful to you?
Thank you for voting!
-
Customer:Thomas from Fort Lauderdale, FL
-
Parts Used:W10827015
-
Difficulty Level:Very Easy
-
Total Repair Time:Less than 15 mins
-
Tools:
Vegetable drawer lid need replacing after it cracked
Very simple to remove from the old lid from the plastic lugs and replace
Was this instruction helpful to you?
Thank you for voting!
-
Customer:Clara from Miami, FL
-
Difficulty Level:Really Easy
-
Total Repair Time:30 - 60 mins
-
Tools:Screw drivers, Wrench (Adjustable), Wrench set
the pantry door was broken
i just i have to removed the old one an i followed the same method to install the new one
Was this instruction helpful to you?
Thank you for voting!
- < Prev
- 1
- Next >
★
Customer Reviews
Filter By Rating:
- < Prev
- 1
- Next >
Sort by:
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Sorry, we couldn't find any existing reviews that matched. Try using some different or simpler keywords.
Leslie H - May 30, 2021
Verified Purchase
Fast
So happy with this part for my fridge. First of all I received in 3 days I had waited 4 months with another company for my part that was backorderd. The Fix I found on line search. It was packaged nicely cello wrapped and was so easy to install my fridge looks brand new inside. Very satisfied.
Jack B - April 21, 2021
Verified Purchase
Wonderful!
It feels like I have a new refrigerator! The replacement was straightforward and your service outstanding! Could not be happier
William S - March 13, 2021
Verified Purchase
Hard part done. (open package) snap it on the pins, DONE
Part is just what I needed, the clips that hold the window into the drawer cover were broke off.
LIKE NEW AGAIN.
