Ice Maker Water Fill Tube Kit
Works With Model RT18BKXSQ00!
$9.89
In Stock
Fix Number: FIX11739222
Manufacturer #: WP2196157
Manufactured by:
Whirlpool
Works With Model RT18BKXSQ00!
-
Product Description
This kit comes with a fill tube and a compression nut.
-
Works with the following brandsKenmore, Whirlpool, KitchenAid, Roper
-
Works with the following productsRefrigerator, Ice Maker, Freezer, Wine and Beverage Cooler
-
Fixes the following symptomsLeaking, Ice maker not making ice, Not dispensing water, Ice maker won’t dispense ice
-
Part Number Cross ReferencePart# WP2196157 replaces these:AP6006156, 1112845, 2154070, 2154080, 2154081, 2174759, 2174760, 2182015, 2196035, 2196157, 836489, 841907, 842896, 848725, 849908, 983655, 983990, W10281566
Product Description
This kit comes with a fill tube and a compression nut.
-
Works with the following brands:Kenmore, Whirlpool, KitchenAid, Roper
-
Works with the following products:Refrigerator, Ice Maker, Freezer, Wine and Beverage Cooler
-
Fixes the following symptoms:Leaking, Ice maker not making ice, Not dispensing water, Ice maker won’t dispense ice
-
Part# WP2196157 replaces these:AP6006156, 1112845, 2154070, 2154080, 2154081, 2174759 ... Show more , 2174760, 2182015, 2196035, 2196157, 836489, 841907, 842896, 848725, 849908, 983655, 983990, W10281566 Show less
Videos For installing this part.
Replacing your Ice Maker Water Fill Tube Kit
Questions and Answers
We're sorry, but our Q&A experts are temporarily unavailable.
Please check back later if you still haven't found the answer you need.
Installation Instructions Provided by Fix customers like you.
- < Prev
- 1
- Next >
Sort by:
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Sorry, we couldn't find any existing installation instruction that matched.
-
Customer:Jim from MINNEAPOLIS, MN
-
Parts Used:WP2196157
-
Difficulty Level:Really Easy
-
Total Repair Time:30 - 60 mins
-
Tools:Pliers, Screw drivers
Ice filler inlet broke off from hitting the wall. Water in the basement resulted.
Turn off the ice maker by raising the arm. Pull the fridge out to access the back. Remove the two screws holding the fill tube to the fridge. Pull the fill tube straight out. Removed threaded broken piece from the old fill tube nut. The old nut wouldn't come off the tube so I used it instead of the new nut that came in the parts kit. Attached the fill tube to the new part. The fill tube fit exactly. I glued a bourbon bottle cork on the back of the fridge next to the fill tube to prevent it from impacting when the fridge is pushed against the wall. Shouldn't ever break again!
Was this instruction helpful to you?
Thank you for voting!
-
Customer:Nazaret from Northridge, CA
-
Difficulty Level:Easy
-
Total Repair Time:30 - 60 mins
-
Tools:Pliers, Screw drivers, Socket set, Wrench (Adjustable)
Incomming Water in the freezer section was freezing some of the water was being sprayed all over
I followed the video instructions to replace (2) items: Icemaker water fill tube kit and dual outlet valve kit. my problem was solved. My particular model the location of the dual valve was on top of refrigerator exposed unlike the video version which shows in the lower back of the refrigerator.
Was this instruction helpful to you?
Thank you for voting!
-
Customer:Paul from Vail, CO
-
Difficulty Level:Really Easy
-
Total Repair Time:30 - 60 mins
-
Tools:Nutdriver
a leak from the icemaker fill tube conection
I watched your video and then the repair was very easy
Was this instruction helpful to you?
Thank you for voting!
-
Customer:Fred from fox lake, IL
-
Parts Used:WP2196157
-
Difficulty Level:Really Easy
-
Total Repair Time:15 - 30 mins
-
Tools:Socket set
cracked elbow on the fill tube-water leaking out the back of the fridge
Once again the website came through. The right part in stock and it shipped the same day I ordered it . Watched a repair video that explained everything. Unplugged the fridge and turned off the water supply to be on the safe side. I used a 1/4 inch socket to remove the screws holding the old part. Then I removed the old part and compared the length of the old and new parts. Got lucky cuz I didn't have to trim the length on the new part. Installed the new part making sure it was all the way in and replaced the screws. Then trimmed about a 1/4 inch off the water line and put in that little metal part. Put the new compression nut on the water line, put the water line into the elbow and finger tightened the nut. Done. 20 minutes. Turned on the water supply, plugged in the fridge, turned on the ice maker and kept an eye on it throughout the day. No more leaks, works perfectly.
Was this instruction helpful to you?
Thank you for voting!
-
Customer:Jennifer from Federal way, WA
-
Difficulty Level:Really Easy
-
Total Repair Time:15 - 30 mins
-
Tools:Nutdriver, Screw drivers
Leaking water out if the ice maker.
Followed the video and did the repair. Works perfectly. The video was excellent, without that I wouldn't have had a clue.
Was this instruction helpful to you?
Thank you for voting!
- < Prev
- 1
- Next >
★
Customer Reviews
Filter By Rating:
- < Prev
- 1
- Next >
Sort by:
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Sorry, we couldn't find any existing reviews that matched. Try using some different or simpler keywords.
Martin B - March 10, 2023
Verified Purchase
Exactly what I ordered!
I have not replaced the part yet but they are exactly the same. You guys are great. With your help it was easy to find the part. Thanks
- < Prev
- 1
- Next >
Model Compatibility
This part works with the following models:
