Dual Radiant Element with Limiter W10823709

Rated by 2 customers

?

Very Easy

Less than 15 mins

Ratings submitted by customers like you who bought this part.

?
$192.10
In Stock
Fix Number:
FIX11759488
Manufacturer #:
W10823709
Manufactured by:
Whirlpool

Jump to:

Product Description

Optimize your cooking experience with this Dual Radiant Surface Element, designed to deliver efficient heat distribution across your range’s cooking surface. Featuring a built-in limiter for safety, this part ensures reliable performance without the risk of overheating. Always unplug the range and verify model compatibility before installation for a smooth replacement.

  • Works with the following brands:
    Maytag, Jenn-Air, Kenmore, Crosley
  • Works with the following products:
    Range, Cooktop, Microwave Oven Combo
  • Fixes the following symptoms:
    Element will not heat
  • Part# W10823709 replaces these:
    AP6030109, 12002144, 12002149, 71002253, 74004556, 74007227 , 74008570, 74008576 Show less
Works with the following brands:
Maytag, Jenn-Air, Kenmore, Crosley
Works with the following products
Range, Cooktop, Microwave Oven Combo
Fixes the following symptoms
Element will not heat
Part Number Cross Reference
Part# W10823709 replaces these:
AP6030109, 12002144, 12002149, 71002253, 74004556, 74007227, 74008570, 74008576

Videos For installing this part.

Replacing your Dual Radiant Element with Limiter

Replacing your Dual Radiant Element with Limiter

Questions and Answers

Ask our experts a question about this part and we'll get back to you as soon as possible!

1 question answered by our experts.
  • 1
Sort by:
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Sorry, we couldn't find any existing answers that matched.
Try using some different or simpler keywords, or submit your new question by using the "Ask a Question" button above!
Dennis
January 4, 2023
Dual burner switch lites up for each burner but neither burner works. I assume the dual burner needs to be replaced. Is that correct? Thanks
For model number CVE3401W
Fix.com logo
Hello Dennis, Thank you for your inquiry. You can test the dual element with a multimeter to make sure it is working properly. If you are unfamiliar with how a multimeter functions, we have videos available to assist you. Good luck with your repair.

Was this helpful?
Thank you for voting!
