2087252-1-M-Whirlpool-74009852-Oven Burner Pilot with Thermal Couple
Part Location Diagram of 74009852 Whirlpool Oven Burner Pilot with Thermal Couple
See part 9 in the diagram
( Grid squares measure 1x1 inch )
2087252-1-S-Whirlpool-74009852-Oven Burner Pilot with Thermal Couple 2087252-2-S-Whirlpool-74009852-Oven Burner Pilot with Thermal Couple 2087252-3-S-Whirlpool-74009852-Oven Burner Pilot with Thermal Couple Part Location Diagram of 74009852 Whirlpool Oven Burner Pilot with Thermal Couple

Oven Burner Pilot with Thermal Couple 74009852

$61.55
On Order
Fix Number:
FIX2087252
Manufacturer #:
74009852
Manufactured by:
Whirlpool

Jump to:

Product Description

This oven pilot burner assembly is a genuine OEM replacement for Whirlpool gas ranges and ovens. It includes the thermocouple and provides the small flame needed to ignite the main burner, ensuring consistent and even heating during cooking. If your oven is experiencing issues such as a weak or intermittent pilot flame, failure to ignite, or uneven heating, replacing this assembly can restore proper functionality. Installation involves disconnecting the gas supply and power, removing the old assembly, and securing the new one in place for safe and reliable operation.

  • Works with the following brands:
    Magic Chef, Amana
  • Works with the following products:
    Range
  • Fixes the following symptoms:
    Will Not Start
  • Part# 74009852 replaces these:
    AP4099055, 1072657, 74009852, 7505P338-60
Works with the following brands:
Magic Chef, Amana
Works with the following products
Range
Fixes the following symptoms
Will Not Start
Part Number Cross Reference
Part# 74009852 replaces these:
AP4099055, 1072657, 74009852, 7505P338-60
