783534-1-M-GE-WB17T10006 -Surface Burner Terminal Block Kit
Part Location Diagram of WB17T10006 GE Surface Burner Terminal Block Kit
See part 961 in the diagram
Replacing your General Electric Range Surface Burner Terminal Block Kit
783534-1-S-GE-WB17T10006 -Surface Burner Terminal Block Kit 360 view
( Grid squares measure 1x1 inch )
783534-1-S-GE-WB17T10006 -Surface Burner Terminal Block Kit 783534-2-S-GE-WB17T10006 -Surface Burner Terminal Block Kit 783534-1-S-GE-WB17T10006 -Surface Burner Terminal Block Kit 360 view
Part Location Diagram of WB17T10006 GE Surface Burner Terminal Block Kit Replacing your General Electric Range Surface Burner Terminal Block Kit

Surface Burner Terminal Block Kit WB17T10006

Rated by 9 customers

?

Easy

15 - 30 mins

Ratings submitted by customers like you who bought this part.

?
$26.10
On Order
Fix Number:
FIX783534
Manufacturer #:
WB17T10006
Manufactured by:
GE

Jump to:

Product Description

The terminal block is the socket for the coiled burner elements of your cooktop or range in order for the burners to heat up. If your element is not heating up or turning on, there may be an issue with the terminal block. If you remove the coiled element and there are signs of corrosion or arcing on the prongs, the terminal block will need to be replaced. To replace the terminal block, you will need access to the sides and back of the range, so you will need to pull the appliance fully out from the wall. Please be sure to disconnect the power supply to your range before beginning this repair, as you will be cutting, removing, and connecting wiring. This is a genuine OEM replacement kit, and it includes the wires with female contacts, the terminal block, and mounting clip.

  • Works with the following brands:
    General Electric, Kenmore, Hotpoint
  • Works with the following products:
    Range
  • Fixes the following symptoms:
    Element will not heat, Will Not Start
  • Part# WB17T10006 replaces these:
    AP3203326, 1038747, WB17T10006, WB17K10003, WB17T10001, WB17X10007
Works with the following brands:
General Electric, Kenmore, Hotpoint
Works with the following products
Range
Fixes the following symptoms
Element will not heat, Will Not Start
Part Number Cross Reference
Part# WB17T10006 replaces these:
AP3203326, 1038747, WB17T10006, WB17K10003, WB17T10001, WB17X10007

Videos For installing this part.

Replacing your Surface Burner Terminal Block Kit

Replacing your Surface Burner Terminal Block Kit

Questions and Answers

Be the first to ask our experts a question about this part!
