Donnie
October 10, 2021
Show me how the drive belts connect
For model number 13ah66of352
Hello Donnie, Thank you for the question. very sorry, we do not have a video for this belt at this time. here is a repair story from another customer that may help." 1.Removed cutting deck. 2.Removed battery and tray. 3.Removed access panel by shift lever and rear fenders. 4.Removed drive pulley from gear box and removed short drive belt. 5.Disconnected both springs and removed the upper dive belt. 6.Removed retaining bolt from bottom of crank shaft. 7.Using pulley puller (gear puller), pulled engine pulley off the shaft. 8.Extracted upper drive belt. 9.Cleaned shaft with extremely fine sand paper, installed new pulley and belt. 10. Reassembled the mower in reverse order." Good luck with the repair!
5 people found this helpful.
Was this helpful?
Thank you for voting!
Mark
March 8, 2023
What are the dimensions on an upper drive belt on a 2011 Troy built pony mower model number is listed
For model number 13an77kg011288803
Hi Mark, thank you for reaching out. According to our research, the approximate dimensions of the Belt, part number FIX10035504, are: Length, 35.25 and Width, O.65 inches. We hope this information helps!
My upper transmission drive belt came off the idler/ tensioner pulley. How do I pull the lever back far enough to get the belt back on?
For model number 247.288842
Hi James, thank you for contacting us. Please follow the following instructions to get the belt back on:
1. Remove the cutting deck.
2. Remove the battery and tray.
3. Remove the access panel by the shift lever and rear fenders.
4. Remove the drive pulley from the gearbox and remove the short drive belt.
5. Disconnect both springs and remove the upper dive belt.
6. Remove the retaining bolt from the bottom of the crankshaft.
7. Using a pulley puller (gear puller), pull the engine pulley off the shaft.
8. Extract the upper drive belt.
9. Clean the shaft with extremely fine sandpaper and install a new pulley and belt.
10. Reassemble the mower in reverse order.
We hope that helps!
1 person found this helpful.
Was this helpful?
Thank you for voting!
Richard
July 27, 2022
Bolens 38" lawnmower.does
Does this belt 95404002 fit
The mowing deck? I need the drive belt too.
For model number 13AM762F765 183629
Hi Richard,
Thank you for your question. Yes, this would be the correct belt for your lawn mower. If you need help placing an order for it, customer service is open 7 days a week and anyone will be happy to assist you. Please feel free to give us a call. We look forward to hearing from you!
Was this helpful?
Thank you for voting!
Frank
July 3, 2023
What is dimensions of drive belt n part number. Thanks.
For model number 13aj693h131
Hi Frank, thank you for a very interesting question. The compatible transmission drive belt for your model is part number FIX9172166. Its length is 77 inches, top width is 0.5 (1/2) inches, and depth is 0.31 inches. We hope this information helps!
When I measured the drive belt it's like 27 1/2 inch. Its the belt from engine to main pulley on deck. It goes on only 2 pulleys total. Can u check that for me. God bless you
For model number 13aj693h131
Hello Frank, thank you for contacting us. The drive belt that goes on two pulleys is part number FIX9173860. Its length is 99 inches and top width is 0.5 inches. We hope this information helps!
