Middle Spray Arm Kit 675808

★★★★★
★★★★★
3 Reviews

Rated by 21 customers

?

Really Easy

15 - 30 mins

Ratings submitted by customers like you who bought this part.

?
$27.04
In Stock
Fix Number:
FIX382824
Manufacturer #:
675808
Manufactured by:
Whirlpool

Jump to:

Product Description

The spray arm works by rotating to distribute water throughout the dishwasher, ensuring that both racks of dishes come out clean. If your dishes are not coming out of the dishwasher as clean as they should be, it may be time to replace the spray arm in your appliance. This kit comes with the upper spray arm, split ring seal, water supply tube, a holder for the tube, and a screw to attach the arm to the mounting bracket. The kit has been redesigned by the manufacturer and no longer includes the upper support or mount, and the supply tube now comes as one piece. If your repair also requires a new mounting bracket, this part can be ordered separately. As this is a genuine OEM parts kit, it is guaranteed to work with your model number. This repair is easy to complete and only requires the use of a Philips screwdriver. The spray arm measures approximately 18 inches long, and all components of the kit are white in color.

  • Works with the following brands:
    Kenmore, KitchenAid, Whirlpool
  • Works with the following products:
    Dishwasher
  • Fixes the following symptoms:
    Not cleaning dishes properly, Leaking, Noisy, Will not fill with water
  • Part# 675808 replaces these:
    AP3115182, 679719, 675808, 3378147, 3379644, 675808 , 675808VP, 9742989, 9742992, 9742995, 9743210 Show less
Works with the following brands:
Kenmore, KitchenAid, Whirlpool
Works with the following products
Dishwasher
Fixes the following symptoms
Not cleaning dishes properly, Leaking, Noisy, Will not fill with water
Part Number Cross Reference
Part# 675808 replaces these:
AP3115182, 679719, 675808, 3378147, 3379644, 675808, 675808VP, 9742989, 9742992, 9742995, 9743210

Videos For installing this part.

Replacing your Middle Spray Arm Kit

Replacing your Middle Spray Arm Kit

Questions and Answers

Be the first to ask our experts a question about this part!
