Part Location Diagram of Z-AC-0032 DeWALT ASSY VALVE PLATE
See part B-81 in the diagram
Replacing your DeVilbiss Compressor ASSY VALVE PLATE
Part Location Diagram of Z-AC-0032 DeWALT ASSY VALVE PLATE Replacing your DeVilbiss Compressor ASSY VALVE PLATE

ASSY VALVE PLATE Z-AC-0032

★★★★★
★★★★★
2 Reviews

Rated by 1 customers

?

Really Easy

30 - 60 mins

Ratings submitted by customers like you who bought this part.

?
$32.96
In Stock
Fix Number:
FIX12511523
Manufacturer #:
Z-AC-0032
Manufactured by:
DeWALT

Jump to:

Product Description

This replacement valve plate assembly is a high quality item designed for use on Craftsman air compressors. It is a genuine manufacturer sourced item that is used to control the airflow into the cylinder. Once the piston starts traveling up, the reeds on the valve plate open and air is sent into the air tank. Overtime the reeds will get worn eventually requiring valve plate replacement. One metal valve plate with reed valves and two rubber seals are included in this assembly. When replacing this valve plate assembly it is also a good time to replace the head gaskets which are sold separately. You will need a wrench set to complete this repair.

  • Works with the following brands:
    DeVilbiss, Craftsman, Porter Cable, Black and Decker
  • Works with the following products:
    Compressor
  • Fixes the following symptoms:
    No compressed air
  • Part# Z-AC-0032 replaces these:
    PZ-AC-0032, Z-AC-0032
Works with the following brands:
DeVilbiss, Craftsman, Porter Cable, Black and Decker
Works with the following products
Compressor
Fixes the following symptoms
No compressed air
Part Number Cross Reference
Part# Z-AC-0032 replaces these:
PZ-AC-0032, Z-AC-0032

Videos For installing this part.

Replacing your ASSY VALVE PLATE

Replacing your ASSY VALVE PLATE
