79075239310 Kenmore Range

First, remove the warming drawer. This allows access to the igniter's plug. Unplug the igniter. The rest of the job is performed within the oven. Remove the bottom (1/4 inch socket). Then remove the next, v shaped piece. The igniter is bolted to the aerator. Remove bolts, and it pulls right off. Reverse these to install new igniter.

I ordered the replacement igniter for the oven portion of the unit from Part select. It shipped very quickly. Upon receiving the igniter it was time to get to work. It took roughly 10 mins to replace and we were back up and running.

Oven ignitor is on the bottom gas unit. Ignitor is in oven and plug is in warmer oven on left wall at very back of warmer oven. It has duel function to light both upper and lower gas burners (in oven). Wires of new plug that I received were shorter than existing wires and would not reach the plug from ignitors center mount location to ... Read more plug at far back of warming unit on left wall. Even if the wires would have been long enough, I couldn't figure out how to "release" the existing plug. Easy solution: Cut old wires at junction of old ignitor (leaving wires as long as possible). Cut new wired as close to new male plug as possible (leaving wires as long as possible on new ignitor). Strip ends of old and new wires and wire nut with porcelin wire nuts (hardest part of job was locating porcelin wire nuts)! After placing wires out of the way of burner and ignitor, reassemble stove parts. AVOID touching new element as oil from hands will decrease the life of the element. Good Luck..
