Direct Drive Water Pump
$72.06
In Stock
Fix Number: FIX11741242
Manufacturer #: WP3363892
Manufactured by:
Whirlpool
-
Product Description
This white direct drive drain pump is intended for use with washing machines that do not have belts. This pump has a backflow flapper valve, and two large ports for water to pass through.
-
Works with the following brandsWhirlpool, KitchenAid, Kenmore, Crosley
-
Works with the following productsWasher, Washer Dryer Combo
-
Fixes the following symptomsLeaking, Will not drain, Leaks water
-
Part Number Cross ReferencePart# WP3363892 replaces these:AP6008110, 3352496, 3363892, WP3363892VP
Product Description
This white direct drive drain pump is intended for use with washing machines that do not have belts. This pump has a backflow flapper valve, and two large ports for water to pass through.
-
Works with the following brands:Whirlpool, KitchenAid, Kenmore, Crosley
-
Works with the following products:Washer, Washer Dryer Combo
-
Fixes the following symptoms:Leaking, Will not drain, Leaks water
-
Part# WP3363892 replaces these:AP6008110, 3352496, 3363892, WP3363892VP
Videos For installing this part.
Replacing your Direct Drive Water Pump

Questions and Answers
We're sorry, but our Q&A experts are temporarily unavailable.
Please check back later if you still haven't found the answer you need.
Installation Instructions Provided by Fix customers like you.
- < Prev
- 1
- Next >
Sort by:
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Sorry, we couldn't find any existing installation instruction that matched.
-
Customer:Rob from Julian, CA
-
Parts Used:WP3363892
-
Difficulty Level:Very Easy
-
Total Repair Time:15 - 30 mins
-
Tools:Pliers, Screw drivers
Water pump replacement
Followed the exact process that was described by everyone else
Was this instruction helpful to you?
Thank you for voting!
-
Customer:Kelly M from Nesconset, NY
-
Parts Used:WP3363892
-
Difficulty Level:Really Easy
-
Total Repair Time:15 - 30 mins
-
Tools:Screw drivers, Socket set
leak
replaced pump
Was this instruction helpful to you?
Thank you for voting!
-
Customer:GEORGE from INDIAN HARBOUR BEACH, FL
-
Difficulty Level:A Bit Difficult
-
Total Repair Time:1- 2 hours
-
Tools:Pliers, Screw drivers
Water leak from left front of washer
Thought it was pump and/or hose so I replaced and still had the leak. After searching available parts, I decided to replace the outer tub seal. Simply removing the top tray around the outer tub gives access to the seal and replacement is very simple. That seal finally stopped the leak.
Was this instruction helpful to you?
Thank you for voting!
-
Customer:Lynn G from Altadena, CA
-
Difficulty Level:Really Easy
-
Total Repair Time:30 - 60 mins
-
Tools:Pliers, Screw drivers
My washer was leaking water so badly, it was draining to the down stairs apartment!!
My Washer is a Washer & Dryer Combo!! I First Disconnected the Power and taped the power cord firmly to the top of washer!! Then i shut off the hot & cold water valves and disconnected the hoses from behind the washer and drained hoses to plastic bucket!! Next i Turned off gas Valve, and disconnected gas hose from the valve!! I then pulled washer out from in back of the wall, and disconnected the dryer vent hose from in back of the dryer!! I then pulled my washer out to an open space and carefully laid it down on its side!! I then Checked out the leaky pump to make sure it matched the replacement pump!! All good, it was a go!! :)) Using a pair of channel lock pliers, i squeezed the hose clamps and moved back just far enough to remove the hoses from the pump!! Then with a screw driver, i unbuckled the pump hold down straps and removed the leaky pump from motor shaft!! My pump removed very easily without use of a screwdriver!! I then lined up new pump with motor shaft, and made sure that the three points lined up right!! After i new that the new pump was aligned properly, I First Secured the 2 Pump Hold Down straps and made sure pump was secured to the motor shaft!! The i put back on the suction and the discharge hoses and secured the clamps to the pump!! At this point my pump repair surgery was complete!! I then stood the machine upright, reconnected everything i described i had either disconnected or unplugged and ran the washer through a Test Cycle!! All good, No Leaks, and back to normal living!! :))
Was this instruction helpful to you?
Thank you for voting!
-
Customer:Diane from Houston, OH
-
Parts Used:WP3363892
-
Difficulty Level:Easy
-
Total Repair Time:Less than 15 mins
-
Tools:Pliers
Washer was leaking. On a completely dry floor, I was able to see that it was in the front part of the washer.
I tilted the washer back and easily identified the problem as the plastic water pump. A pair of pliers quickly released the clamps securing the hoses and the part came off. My first thought was to go to town and attempt to find the part. I'm in my late 50's and this is what we do. I realized that the part # was staring at me so I, for the first time ever, sat at the computer and typed in " KitchenAid washer parts." The first thing to pop up was a place for the part #. A picture of the part. Very easy ordering and in 3 days it appeared at my house. Reattached the hoses, tilted the washer down and I'm back in business.
Was this instruction helpful to you?
Thank you for voting!
- < Prev
- 1
- Next >
Model Compatibility
This part works with the following models:
Fix Number: FIX11741242
Manufacturer Part Number: WP3363892
Manufacturer Part Number: WP3363892
