271510-1-S-GE-WH2X1198 -Tub Bearing 360 view

Tub Bearing

Rated by 3 customers

Easy

1- 2 hours

Ratings submitted by customers like you who bought this part.

$26.86

Fix Number: FIX271510

Manufacturer #: WH2X1198

Manufactured by: GE

Product Description

The tub bearing secures the spin basket in the tub assembly of a washer. It is located on the bottom of the outer tub. A common symptom of a worn tub bearing is a very loud noise (including a grinding sound) during the spin cycle. If the washer is also having trouble spinning or agitating, it leaks, or shakes, these are also indications that the tub bearing may need to be replaced. This part is sold individually and is sourced right from the original manufacturer.
Works with the following brands

General Electric, Hotpoint
Works with the following products
Washer
Fixes the following symptoms

Leaking
Part Number Cross Reference

Part# WH2X1198 replaces these:

AP2045289, 279136, WH02X1198

1 Installation Video

6 Related Parts 1 Question and Answer

3 Installation Instructions Model Compatibility

Product Description Part Videos Questions and Answers Related Parts Installation Instructions Model Compatibility

Product Description

The tub bearing secures the spin basket in the tub assembly of a washer. It is located on the bottom of the outer tub. A common symptom of a worn tub bearing is a very loud noise (including a grinding sound) during the spin cycle. If the washer is also having trouble spinning or agitating, it leaks, or shakes, these are also indications that the tub bearing may need to be replaced. This part is sold individually and is sourced right from the original manufacturer.

Works with the following brands:

General Electric, Hotpoint
Works with the following products:
Washer
Fixes the following symptoms:

Leaking
Part# WH2X1198 replaces these:

AP2045289, 279136, WH02X1198

Videos For installing this part.

Replacing your Tub Bearing

Questions and Answers

Ask our experts a question about this part and we'll get back to you as soon as possible!

1 question answered by our experts.

< Prev
1
Next >

Sort by:

Thomas

March 30, 2022

how can i tell if the bearing is bad before i take things apart

For model number htwp1000m2www

Hello Thomas, Thank you for the question. If you hear a metal-on-metal sound at the bottom of the machine it is more than likely the bearing. I hope this helps and good luck with your repair.

1 person found this helpful.

Was this helpful?

< Prev
1
Next >

Related PartsAdditional or alternate parts to consider.

Installation Instructions Provided by Fix customers like you.

Average Repair Rating: 2.5 / 5.0, 3 reviews.

< Prev
1
Next >

Sort by:

Customer:

Joe from Chillicothe, MO
Parts Used:
WH02X10383, WH02X10265, WH01X10302, WH2X1199, WH2X1198, WH2X1197
Difficulty Level:
A Bit Difficult
Total Repair Time:
1- 2 hours
Tools:
Nutdriver, Pliers, Screw drivers, Socket set, Wrench (Adjustable), Wrench set

Leaking & very Noisy

Watched the Video took parts off one by one got as far as the nut there there had a problem with it had to soak it in W D 40 then was able to get it off needed to buy a new Nut split ring broke when i took it off but i have ordered the parts a head of time all of the main parts were rusted bearings ,hub washer,so it was a good thing i got all of the main parts the belt was starting to show wear. got a new one but as for the loud noise I found that the Transmission bearing went bad so ill have to get a new one. The job was not all that hard the nut was the main problem the seal was a bit hard to get off so i the whole tub out of the Machine had it upside down and put a screw driver thru hole and pop it out that way the tub bearing was the same way flip tub over a pop it out from the front when seal was out found it works better that way then the way it shows in the Video put a little liquid of soap around edge of seal it goes on much better Hope all this helps you out

7 of 7 people found this instruction helpful.

Was this instruction helpful to you?

Customer:

Stephen from Bridgewater, NJ
Parts Used:
WH02X10383, WH38X10017, WH02X10265, WE03X29897, WH01X10302, WH2X1199, WH2X1198, WH2X1197, WE25M40
Difficulty Level:
Really Easy
Total Repair Time:
30 - 60 mins
Tools:

noisy

New shaft, belt and housing. Installation was going fine until went to install belt and IT was way to short .THANKS

5 of 7 people found this instruction helpful.

Was this instruction helpful to you?

Customer:

Carol from Pitman, PA
Parts Used:
WH45X20473, WH02X10383, WH02X10284, WH02X10265, WH2X1198, WH2X1193
Difficulty Level:
A Bit Difficult
Total Repair Time:
More than 2 hours
Tools:
Nutdriver, Pliers, Socket set

Washer tub seal leak and mode shifter noisy

Disconnect power and water supply hoses, remove back cover and control panel, remove lid switch, then lid. Unsnapped top ring on tub assembly, disconnect pressure tube, disconnect motor control wires, twist and remove center fabric softener cup, removed hex bolt underneath, then removed agitator and drive hub. Used 1 11/16" 3/4 drive socket with extensions and breaker bar. Used sledge hammer on bar to knock loose left-hand thread aluminum tub nut(quite difficult on a 6 year old washer). Lift stainless tub out and removed split ring and old seal. Tip out plastic tub assembly and turn upside down to remove drive belt, and pulley. Removed all hardware connecting drive assembly to plastic tub and installed new parts. TIP: install tub seal after mode shifter is installed and do not use any gasket sealer or lube as seal will want to push back out. Old tub assembly was replaced due to elongated and cracked tub seal seat.

2 of 3 people found this instruction helpful.

Was this instruction helpful to you?

< Prev
1
Next >

Model Compatibility

This part works with the following models:

Fix Number: FIX271510
Manufacturer Part Number: WH2X1198

General Electric

56221B3WW

Washer

General Electric

56241B3WW

Washer

General Electric

56251B2WW

Washer

General Electric

56411D0WW

Washer

General Electric

56411D5WW

Washer

General Electric

56421D0WW

Washer

General Electric

56421D5WW

Washer

General Electric

56421DAWW

Washer

General Electric

57271B2WW

Washer

General Electric

57281B5WW

Washer

General Electric

57431D0WW

Washer

General Electric

57431D5WW

Washer

General Electric

57431DAWW

General Electric

57431DCWW

General Electric

57441D0WW

Washer

General Electric

57441D5WW

Washer

General Electric

57441DAWW

General Electric

57441DCWW

Washer

General Electric

57481D0WW

Washer

General Electric

57481D1WW

Washer

General Electric

57481DCWW

Washer

General Electric

57491D0WW

Washer

General Electric

57491D1WW

Washer

General Electric

57731H0WW

Washer

General Electric

57731H2WW

Washer

General Electric

57731H3WW

Washer

General Electric

57731H5WW

Washer

General Electric

57731H6WW

Washer

General Electric

57731H7WW

Washer

General Electric

57731H8WW

Washer
