Split Ring
Works With Model HTWP1400F1WW!
$14.06
In Stock
Fix Number: FIX1766022
Manufacturer #: WH02X10265
Manufactured by:
GE
Works With Model HTWP1400F1WW!
-
Product Description
This split ring is two inches in diameter.
-
Works with the following brandsGeneral Electric, Hotpoint
-
Works with the following productsWasher
-
Fixes the following symptomsLeaking, Will not agitate
-
Part Number Cross ReferencePart# WH02X10265 replaces these:AP4324356, 1394382, WH02X1195, WH2X1195
Product Description
This split ring is two inches in diameter.
-
Works with the following brands:General Electric, Hotpoint
-
Works with the following products:Washer
-
Fixes the following symptoms:Leaking, Will not agitate
-
Part# WH02X10265 replaces these:AP4324356, 1394382, WH02X1195, WH2X1195
Videos For installing this part.
Replacing your Split Ring

Questions and Answers
We're sorry, but our Q&A experts are temporarily unavailable.
Please check back later if you still haven't found the answer you need.
Related PartsAdditional or alternate parts to consider.
Installation Instructions Provided by Fix customers like you.
- < Prev
- 1
- Next >
Sort by:
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Sorry, we couldn't find any existing installation instruction that matched.
-
Customer:Joe from Chillicothe, MO
-
Difficulty Level:A Bit Difficult
-
Total Repair Time:1- 2 hours
-
Tools:Nutdriver, Pliers, Screw drivers, Socket set, Wrench (Adjustable), Wrench set
Leaking & very Noisy
Watched the Video took parts off one by one got as far as the nut there there had a problem with it had to soak it in W D 40 then was able to get it off needed to buy a new Nut split ring broke when i took it off but i have ordered the parts a head of time all of the main parts were rusted bearings ,hub washer,so it was a good thing i got all of the main parts the belt was starting to show wear. got a new one but as for the loud noise I found that the Transmission bearing went bad so ill have to get a new one. The job was not all that hard the nut was the main problem the seal was a bit hard to get off so i the whole tub out of the Machine had it upside down and put a screw driver thru hole and pop it out that way the tub bearing was the same way flip tub over a pop it out from the front when seal was out found it works better that way then the way it shows in the Video put a little liquid of soap around edge of seal it goes on much better Hope all this helps you out
Was this instruction helpful to you?
Thank you for voting!
-
Customer:Dean from Parker, CO
-
Difficulty Level:A Bit Difficult
-
Total Repair Time:30 - 60 mins
-
Tools:Pliers, Screw drivers, Socket set, Wrench (Adjustable)
Washer leaking and noisy
Follow the videos. They explain how to do this repair extremely well. Don't forget that the nut that holds the basket is a left-hand thread. I used a pipe wrench and a hammer to break it loose. I used a screwdriver to stab the old seal and pry it out without damaging the tub. It came out pretty easily. I used hand soap to lubricate the new seal and fit it in after cleaning out the tub's seal seat. It's a relatively easy job and now it doesn't leak and the noise is greatly reduced. I also lubricated the bearings with Lithium grease but that required taking the entire machine apart which is also explained in another video......
Was this instruction helpful to you?
Thank you for voting!
-
Customer:Ryan from Stuarts Draft, VA
-
Difficulty Level:A Bit Difficult
-
Total Repair Time:More than 2 hours
-
Tools:Nutdriver, Socket set, Wrench set
when we would let the clothes soak, it would leak from the bottom seal.
I used youtube to figure out what i needed. After trying to get the large backwards threaded nut off with my rachet, i ended up taking it to my buddys house and using his impact gun. It was a breeze after i was able to get the nut off. While it was all apart, i cleaned all the old detergant off that was built up under the agrator.
Was this instruction helpful to you?
Thank you for voting!
-
Customer:Stephen from Bridgewater, NJ
-
Parts Used:WH02X10383, WH38X10017, WH02X10265, WE03X29897, WH01X10302, WH2X1199, WH2X1198, WH2X1197, WE25M40
-
Difficulty Level:Really Easy
-
Total Repair Time:30 - 60 mins
-
Tools:
noisy
New shaft, belt and housing. Installation was going fine until went to install belt and IT was way to short .THANKS
Was this instruction helpful to you?
Thank you for voting!
-
Customer:Carol from Pitman, PA
-
Difficulty Level:A Bit Difficult
-
Total Repair Time:More than 2 hours
-
Tools:Nutdriver, Pliers, Socket set
Washer tub seal leak and mode shifter noisy
Disconnect power and water supply hoses, remove back cover and control panel, remove lid switch, then lid. Unsnapped top ring on tub assembly, disconnect pressure tube, disconnect motor control wires, twist and remove center fabric softener cup, removed hex bolt underneath, then removed agitator and drive hub. Used 1 11/16" 3/4 drive socket with extensions and breaker bar. Used sledge hammer on bar to knock loose left-hand thread aluminum tub nut(quite difficult on a 6 year old washer). Lift stainless tub out and removed split ring and old seal. Tip out plastic tub assembly and turn upside down to remove drive belt, and pulley. Removed all hardware connecting drive assembly to plastic tub and installed new parts. TIP: install tub seal after mode shifter is installed and do not use any gasket sealer or lube as seal will want to push back out. Old tub assembly was replaced due to elongated and cracked tub seal seat.
Was this instruction helpful to you?
Thank you for voting!
- < Prev
- 1
- Next >
