6-Rib Drive Belt

Works With Model GTWN5250D0WW!

★★★★★

2 Reviews

Rated by 5 customers

Easy

30 - 60 mins

Ratings submitted by customers like you who bought this part.

$25.12

Fix Number: FIX1482278

Manufacturer #: WH01X10302

Manufactured by: GE

Works With Model GTWN5250D0WW!

Product Description

This is a 6-rib washer drive belt. It is sourced directly from the original manufacturer and constructed with a durable Poly V material. This part connects the drive motor to the drive system that turns the basket. This part is susceptible to wear and tear and will need to be replaced over the lifetime of your washer. Please be advised that this belt is very tight, and it can be difficult to get it around the pulley system. An installation tool may be required to perform this installation, which is sold separately.
Works with the following brands

General Electric, Hotpoint
Works with the following products
Washer
Fixes the following symptoms

Will not agitate, Spins slowly, Will not drain, Burning smell
Part Number Cross Reference

Part# WH01X10302 replaces these:

AP3968432, 1264395, WH01X10353

1 Installation Video Questions and Answers

5 Installation Instructions

2 Customer Reviews Model Compatibility

Product Description Part Videos Questions and Answers Installation Instructions Customer Reviews Model Compatibility

Product Description

This is a 6-rib washer drive belt. It is sourced directly from the original manufacturer and constructed with a durable Poly V material. This part connects the drive motor to the drive system that turns the basket. This part is susceptible to wear and tear and will need to be replaced over the lifetime of your washer. Please be advised that this belt is very tight, and it can be difficult to get it around the pulley system. An installation tool may be required to perform this installation, which is sold separately.

Works with the following brands:

General Electric, Hotpoint
Works with the following products:
Washer
Fixes the following symptoms:

Will not agitate, Spins slowly, Will not drain, Burning smell
Part# WH01X10302 replaces these:

AP3968432, 1264395, WH01X10353

Videos For installing this part.

Replacing your 6-Rib Drive Belt

Questions and Answers

Be the first to ask our experts a question about this part!

Installation Instructions Provided by Fix customers like you.

Average Repair Rating: 3.5 / 5.0, 5 reviews.

< Prev
1
Next >

Sort by:

Customer:

Joe from Chillicothe, MO
Parts Used:
WH02X10383, WH02X10265, WH01X10302, WH2X1199, WH2X1198, WH2X1197
Difficulty Level:
A Bit Difficult
Total Repair Time:
1- 2 hours
Tools:
Nutdriver, Pliers, Screw drivers, Socket set, Wrench (Adjustable), Wrench set

Leaking & very Noisy

Watched the Video took parts off one by one got as far as the nut there there had a problem with it had to soak it in W D 40 then was able to get it off needed to buy a new Nut split ring broke when i took it off but i have ordered the parts a head of time all of the main parts were rusted bearings ,hub washer,so it was a good thing i got all of the main parts the belt was starting to show wear. got a new one but as for the loud noise I found that the Transmission bearing went bad so ill have to get a new one. The job was not all that hard the nut was the main problem the seal was a bit hard to get off so i the whole tub out of the Machine had it upside down and put a screw driver thru hole and pop it out that way the tub bearing was the same way flip tub over a pop it out from the front when seal was out found it works better that way then the way it shows in the Video put a little liquid of soap around edge of seal it goes on much better Hope all this helps you out

7 of 7 people found this instruction helpful.
