291908-1-M-GE-WR17X10706 -Dispenser Door Recess Crank

GE/GE_Thumb/00120714i01.gif

See part 67 in the diagram

Replacing your General Electric Refrigerator Dispenser Door Recess Crank

play video

( Grid squares measure 1x1 inch )

Dispenser Door Recess Crank

$11.97

Fix Number: FIX291908

Manufacturer #: WR17X10706

Manufactured by: GE

Product Description

The door recess crank for your refrigerator is located inside the water dispenser assembly. To access this part, you will need to take apart the dispenser assembly. To do this, you will need a putty knife and a Phillips screwdriver. If your dispenser door will not close properly, or ice is not dispensing properly, you may have a damaged door recess crank. This part is made of white plastic and is sold individually.
Works with the following brands

General Electric, Hotpoint
Works with the following products
Refrigerator
Fixes the following symptoms

Door Sweating, Ice maker won’t dispense ice, Door won’t open or close, Not dispensing water
Part Number Cross Reference

Part# WR17X10706 replaces these:

AP3185409, 913457

1 Installation Video

3 Related Parts

Questions and Answers

Questions and Answers

8 Installation Instructions

Model Compatibility

Product Description Part Videos Questions and Answers Related Parts Installation Instructions Model Compatibility

Product Description

The door recess crank for your refrigerator is located inside the water dispenser assembly. To access this part, you will need to take apart the dispenser assembly. To do this, you will need a putty knife and a Phillips screwdriver. If your dispenser door will not close properly, or ice is not dispensing properly, you may have a damaged door recess crank. This part is made of white plastic and is sold individually.

Works with the following brands:

General Electric, Hotpoint
Works with the following products:
Refrigerator
Fixes the following symptoms:

Door Sweating, Ice maker won’t dispense ice, Door won’t open or close, Not dispensing water
Part# WR17X10706 replaces these:

AP3185409, 913457

Videos For installing this part.

Replacing your Dispenser Door Recess Crank

Replacing your Dispenser Door Recess Crank

play video

Questions and Answers

Questions and Answers

Be the first to ask our experts a question about this part!

Related PartsAdditional or alternate parts to consider.

Installation Instructions Provided by Fix customers like you.

Average Repair Rating: 4.0 / 5.0, 8 reviews.

< Prev
1
Next >

Sort by:

Customer:

Malcolm from St Petersburg, FL
Parts Used:
WR49X10233, WR62X10055, WR17X11653, WR17X10706, WR02X10585
Difficulty Level:
Really Easy
Total Repair Time:
15 - 30 mins
Tools:
Screw drivers

flapper not working

Ordered parts, watched video. That easy. The best parts company I ever ordered from. Each part had a video to help you uninstall, repair and reinstall. coul;d'nt be any easier.

1 person found this instruction helpful.

Was this instruction helpful to you?

Customer:

Klark from Orlando, FL
Parts Used:
WR62X10055, WR17X11653, WR17X10706, WR02X10585
Difficulty Level:
Very Easy
Total Repair Time:
15 - 30 mins
Tools:
Pliers, Screw drivers

Freezer door flap would not close from the ice dispenser and the door would collect a block of solid ice.

Follow the installation videos they have on their website and it's very easy to replace all of these parts. Only issue I had was the top screw on the selenoid had rusted in place and instead of trying to get it out I simply wiggled the old part out, and wiggled the new one in its place. It worked great. My model has black shiny plastic inserts for the freezer and refrigerator door and it is easier to take the top trim molding off the freezer door to slide out the decorative plastic which allows you to pop the frame around the icemaker out much easier. Careful not to break clips on the decorative trim.

0 of 1 people found this instruction helpful.

Was this instruction helpful to you?

Customer:

george from miami, FL
Parts Used:
WR62X10055, WR17X11653, WR17X10706, WR02X10585
Difficulty Level:
Easy
Total Repair Time:
1- 2 hours
Tools:
Screw drivers

the ice door was not closing

I followed the videos that you guys had on the internet step by step which made the job of installation easy.

0 of 1 people found this instruction helpful.

Was this instruction helpful to you?

Customer:

Robert from Auburn, WA
Parts Used:
WR62X10055, WR17X11653, WR17X10706
Difficulty Level:
Really Easy
Total Repair Time:
15 - 30 mins
Tools:
Screw drivers

Icing problem in freezer compartment, and water draining into catch pan in door recess.

(1)Remove plastic bezel trim plate surrounding in-door service recess. (2)Remove lower screw that holds motherboard in place. (3)Remove motherboard and wiring clip harnesses x 3. (4)Remove x3 retaining screws that anchor door flap seleniod. (5)Remove seleniod action pin and retaining crank arm w/flap. (6)Reassemble in opposite format with new components. Easy peasy lemon sqeezey...

0 of 1 people found this instruction helpful.

Was this instruction helpful to you?

Customer:

David from Rumford, RI
Parts Used:
WR62X10055, WR17X11653, WR17X10706, WR02X10585
Difficulty Level:
Really Easy
Total Repair Time:
30 - 60 mins
Tools:
Screw drivers

Ice maker Door would not Close

I watched the U Tube and followed the Instructions. We found a Lot of Mold around the Door, & Rust around the Door Solenoid. Be careful when removing the Outer plastic Frame and Push button panel..

0 of 1 people found this instruction helpful.

Was this instruction helpful to you?

Customer:

peter from bayville, NJ
Parts Used:
WR62X10055, WR17X11653, WR17X10706, WR02X10585
Difficulty Level:
Really Easy
Total Repair Time:
15 - 30 mins
Tools:
Screw drivers

flapper was stuck open forming ice build up

I folllowed your excellent video had no problem also parts were order 2am friday I received them saturday at 1pm.(great service)

0 of 1 people found this instruction helpful.

Was this instruction helpful to you?

Customer:

Robert from Tampa, FL
Parts Used:
WR62X10055, WR17X11653, WR17X10706, WR02X10585
Difficulty Level:
Really Easy
Total Repair Time:
15 - 30 mins
Tools:
Screw drivers

The in-door ice maker flapper door had stopped opening to allow ice to fall into the glass

Similar to online videos for other GE in-door models. Unplug. Pull the in-door water/ice control panel out from the bottom, it is a click fit. Unplug the 3 wire harness fittings from the back of the board and set it aside. remove the 4 screws at the corners of the paddle housing and remove. All of the flapper solenoid, door spring and crank are now exposed. Remove old solenoid by removing 2 bottom screws and loosening the top screw, then pull it out at the bottom and slide off of upper screw. Remove plunger hanging form door crank. Remove door crank and spring held in by screws. Assemble new flapper onto crank (click fit) and replace crank and spring into door. Hang new solenoid plunger onto crank arm, and reinstall solenoid with 3 screws. Reinstall paddle housing with 4 screws. Reinsert 3 wire harness connecters onto back of control board. Slide control board into recess at the top and click bottom into place.

0 of 1 people found this instruction helpful.

Was this instruction helpful to you?

Customer:

Patrick from St. Pete Beach, FL
Parts Used:
WR62X10055, WR17X10706
Difficulty Level:
Really Easy
Total Repair Time:
15 - 30 mins
Tools:
Screw drivers

Freezer icing up dripping through open ice & water door

From watching a step by step instruction video on YouTube

0 of 1 people found this instruction helpful.

Was this instruction helpful to you?

< Prev
1
Next >

Model Compatibility

This part works with the following models:

Fix Number: FIX291908
Manufacturer Part Number: WR17X10706

General Electric

A4425GDTABB

Refrigerator

General Electric

A4425GDTAWW

Refrigerator

General Electric

A4425GDTBBB

Refrigerator

General Electric

A4425GDTBWW

Refrigerator

General Electric

A4425GDTW

Refrigerator - GE Refrigerator Model A4425GDTW Parts

General Electric

BSS25GFPACC

Refrigerator

General Electric

BSS25GFPAWW

Refrigerator

General Electric

BSS25GFPCCC

Refrigerator

General Electric

BSS25GFPCWW

Refrigerator

General Electric

BSS25GFPDCC

Refrigerator

General Electric

BSS25GFPDWW

Refrigerator

General Electric

BSS25GFPECC

Refrigerator

General Electric

BSS25GFPEWW

Refrigerator

General Electric

BSS25GFPHCC

Refrigerator

General Electric

BSS25GFPHWW

Refrigerator

General Electric

BSS25JFRFWW

Refrigerator

General Electric

BSS25JFRJWW

Refrigerator

General Electric

BSS25JFTAWW

Refrigerator

General Electric

BSS25JFTBWW

Refrigerator - T Series

General Electric

BSS25JFTCWW

Refrigerator - T Series

General Electric

BSS25JFTDWW

Refrigerator

General Electric

BSS25JFTEWW

Refrigerator - T Series

General Electric

BSS25JFTGWW

Refrigerator

General Electric

BSS25JFTHWW

Refrigerator

General Electric

BSS25JFTIWW

Refrigerator

General Electric

BSS25JFTJWW

Refrigerator

General Electric

BSS25JFTNWW

Refrigerator

General Electric

BSS25JFTPWW

Refrigerator

General Electric

BSS25JSRFSS

Refrigerator

General Electric

BSS25JSRJSS

Refrigerator
