Watch the install video

285013-1-M-GE-WR02X10585-Recess Door Spring

( Grid squares measure 1x1 inch )

285013-1-S-GE-WR02X10585-Recess Door Spring

285013-1-S-GE-WR02X10585-Recess Door Spring 360 view

Part Location Diagram of WR02X10585 GE Recess Door Spring

Replacing your General Electric Refrigerator Recess Door Spring

Recess Door Spring

Works With Model 4070600!

Rated by 10 customers

Really Easy

30 - 60 mins

Ratings submitted by customers like you who bought this part.

$11.99

Fix Number: FIX285013

Manufacturer #: WR02X10585

Manufactured by: GE

Works With Model 4070600!

Product Description

This door recess spring or dispenser lever spring in your refrigerator is used to return the ice door to the closed position or the dispenser lever to the home position once released. You will find the spring in the water dispenser assembly, behind the main control panel. If the dispenser lever is malfunctioning or the dispenser ice door is not closing, you may need to replace this door recess spring.
Works with the following brands

General Electric, Hotpoint
Works with the following products
Refrigerator, Dishwasher
Fixes the following symptoms

Door latch failure, Door Sweating, Ice maker won’t dispense ice, Door won’t open or close
Part Number Cross Reference

Part# WR02X10585 replaces these:

AP3670155, 879075, WR2X10585

1 Installation Video

5 Related Parts Questions and Answers

10 Installation Instructions Model Compatibility

Product Description Part Videos Questions and Answers Related Parts Installation Instructions Model Compatibility

Product Description

This door recess spring or dispenser lever spring in your refrigerator is used to return the ice door to the closed position or the dispenser lever to the home position once released. You will find the spring in the water dispenser assembly, behind the main control panel. If the dispenser lever is malfunctioning or the dispenser ice door is not closing, you may need to replace this door recess spring.

Works with the following brands:

General Electric, Hotpoint
Works with the following products:
Refrigerator, Dishwasher
Fixes the following symptoms:

Door latch failure, Door Sweating, Ice maker won’t dispense ice, Door won’t open or close
Part# WR02X10585 replaces these:

AP3670155, 879075, WR2X10585

Videos For installing this part.

Replacing your Recess Door Spring

Replacing your Recess Door Spring

Questions and Answers

Be the first to ask our experts a question about this part!

Related PartsAdditional or alternate parts to consider.

Installation Instructions Provided by Fix customers like you.

Average Repair Rating: 3.9 / 5.0, 10 reviews.

< Prev
1
Next >

Sort by:

Customer:

Lorraine from Nashwauk, MN
Parts Used:
WR17X11653, WR02X10585
Difficulty Level:
Really Easy
Total Repair Time:
30 - 60 mins
Tools:
Pliers, Screw drivers

Frsot build up and ice not coming out of shoot.

Couldn't get the trim board off, don't waste your time trying to do that. Remove the control panel by inserting screw driver in three holes. Lift up and out. Then you can follow the rest of the video explaining how to get your parts in.

1 person found this instruction helpful.

Was this instruction helpful to you?

Customer:

Malcolm from St Petersburg, FL
Parts Used:
WR49X10233, WR62X10055, WR17X11653, WR17X10706, WR02X10585
Difficulty Level:
Really Easy
Total Repair Time:
15 - 30 mins
Tools:
Screw drivers

flapper not working

Ordered parts, watched video. That easy. The best parts company I ever ordered from. Each part had a video to help you uninstall, repair and reinstall. coul;d'nt be any easier.

1 person found this instruction helpful.

Was this instruction helpful to you?

Customer:

Klark from Orlando, FL
Parts Used:
WR62X10055, WR17X11653, WR17X10706, WR02X10585
Difficulty Level:
Very Easy
Total Repair Time:
15 - 30 mins
Tools:
Pliers, Screw drivers

Freezer door flap would not close from the ice dispenser and the door would collect a block of solid ice.

Follow the installation videos they have on their website and it's very easy to replace all of these parts. Only issue I had was the top screw on the selenoid had rusted in place and instead of trying to get it out I simply wiggled the old part out, and wiggled the new one in its place. It worked great. My model has black shiny plastic inserts for the freezer and refrigerator door and it is easier to take the top trim molding off the freezer door to slide out the decorative plastic which allows you to pop the frame around the icemaker out much easier. Careful not to break clips on the decorative trim.

0 of 1 people found this instruction helpful.

Was this instruction helpful to you?

Customer:

Steven from Newark, NY
Parts Used:
WR62X10055, WR02X10585
Difficulty Level:
Easy
Total Repair Time:
15 - 30 mins
Tools:
Screw drivers

door on ice dispenser not closing tightly

Recommend watching the videos by this site which are excellent. Once front panel is removed and access is gained, the few screws removed to replace the door spring and the solenoid is straight forward and easy. Once back together, hearing the dispenser door 'snap' shut was very nice. Also, kudos to this site on how quickly that they shipped the order!

0 of 1 people found this instruction helpful.

Was this instruction helpful to you?

Customer:

george from miami, FL
Parts Used:
WR62X10055, WR17X11653, WR17X10706, WR02X10585
Difficulty Level:
Easy
Total Repair Time:
1- 2 hours
Tools:
Screw drivers

the ice door was not closing

I followed the videos that you guys had on the internet step by step which made the job of installation easy.

0 of 1 people found this instruction helpful.

Was this instruction helpful to you?

Customer:

David from Rumford, RI
Parts Used:
WR62X10055, WR17X11653, WR17X10706, WR02X10585
Difficulty Level:
Really Easy
Total Repair Time:
30 - 60 mins
Tools:
Screw drivers

Ice maker Door would not Close

I watched the U Tube and followed the Instructions. We found a Lot of Mold around the Door, & Rust around the Door Solenoid. Be careful when removing the Outer plastic Frame and Push button panel..

0 of 1 people found this instruction helpful.

Was this instruction helpful to you?

Customer:

Ron from Montgomery, AL
Parts Used:
WD13X10045, WR02X10585
Difficulty Level:
Really Easy
Total Repair Time:
15 - 30 mins
Tools:
Screw drivers

Broken latch on dishwasher

Due to an injury to my hand, my wife attempted to repair the latch on our dishwasher by watching the video on this site. The only difficulty was in disconnecting the piece that held the control panel to the door. In the video, the guy's arm is in the way so she wasn't sure how to remove the clip that held it in place. The rest of the repair went very smoothly and she was very proud of herself for fixing the dishwasher. By the way, the parts arrived here in less than 24 hours.

0 of 1 people found this instruction helpful.

Was this instruction helpful to you?

Customer:

peter from bayville, NJ
Parts Used:
WR62X10055, WR17X11653, WR17X10706, WR02X10585
Difficulty Level:
Really Easy
Total Repair Time:
15 - 30 mins
Tools:
Screw drivers

flapper was stuck open forming ice build up

I folllowed your excellent video had no problem also parts were order 2am friday I received them saturday at 1pm.(great service)

0 of 1 people found this instruction helpful.

Was this instruction helpful to you?

Customer:

Robert from Tampa, FL
Parts Used:
WR62X10055, WR17X11653, WR17X10706, WR02X10585
Difficulty Level:
Really Easy
Total Repair Time:
15 - 30 mins
Tools:
Screw drivers

The in-door ice maker flapper door had stopped opening to allow ice to fall into the glass

Similar to online videos for other GE in-door models. Unplug. Pull the in-door water/ice control panel out from the bottom, it is a click fit. Unplug the 3 wire harness fittings from the back of the board and set it aside. remove the 4 screws at the corners of the paddle housing and remove. All of the flapper solenoid, door spring and crank are now exposed. Remove old solenoid by removing 2 bottom screws and loosening the top screw, then pull it out at the bottom and slide off of upper screw. Remove plunger hanging form door crank. Remove door crank and spring held in by screws. Assemble new flapper onto crank (click fit) and replace crank and spring into door. Hang new solenoid plunger onto crank arm, and reinstall solenoid with 3 screws. Reinstall paddle housing with 4 screws. Reinsert 3 wire harness connecters onto back of control board. Slide control board into recess at the top and click bottom into place.

0 of 1 people found this instruction helpful.

Was this instruction helpful to you?

Customer:

Michael from Council Bluffs, IA
Parts Used:
WR17X11653, WR02X10585
Difficulty Level:
Really Easy
Total Repair Time:
30 - 60 mins
Tools:
Nutdriver, Screw drivers

Frost buildup in icemaker opening

I tried to follow the video about removing the plate/cover around the dispenser area but to no avail. I broke two of the screws before I ended up removing the inside of the door. After removing the inside of the door the repair went as described in the video except it seemed to be much easier since it was all out in the open and you could see everything clearly. Take care putting the dispenser back in the door, make sure you get the water tube in the right place or you will have to take it apart again to make it right. Easy repair.

0 of 1 people found this instruction helpful.

Was this instruction helpful to you?

< Prev
1
Next >

Model Compatibility

This part works with the following models:

Fix Number: FIX285013
Manufacturer Part Number: WR02X10585

General Electric

40201-0

Dishwasher

General Electric

402011

Dishwasher

General Electric

40205-0

Dishwasher

General Electric

402051

Dishwasher

General Electric

40206-0

Dishwasher

General Electric

402061

Dishwasher

General Electric

402070

Dishwasher

General Electric

403110

Dishwasher

General Electric

403111

Dishwasher

General Electric

405010

Dishwasher

General Electric

405011

Dishwasher

General Electric

405012

Dishwasher

General Electric

405050

Dishwasher

General Electric

405051

Dishwasher

General Electric

405052

Dishwasher

General Electric

405060

Dishwasher

General Electric

405061

Dishwasher

General Electric

405062

Dishwasher

General Electric

4070100

Dishwasher

General Electric

4070110

Dishwasher

General Electric

4070500

Dishwasher

General Electric

4070510

General Electric

4070600

Dishwasher

General Electric

4070610

Dishwasher

General Electric

4070800

Dishwasher

General Electric

4070810

General Electric

4071100

Dishwasher

General Electric

4071110

General Electric

4071120

Dishwasher

General Electric

4071500

Dishwasher
