Ice Maker
Works With Model HSM25GFRESA!
$210.96
In Stock
Fix Number: FIX1993870
Manufacturer #: WR30X10093
Manufactured by:
GE
Works With Model HSM25GFRESA!
-
Product Description
The ice maker assembly makes ice by filling the tray with water from the inlet valve, freezing it until solid cubes are formed, and then ejecting them into the ice bucket. This process will repeat until the bucket has reached capacity. If your fridge is no longer making ice, the assembly may need to be replaced. This is a genuine OEM replacement that measures 10 inches by 5 inches in size and will make seven crescent shaped pieces of ice each cycle. The kit is mainly made of white plastic, and includes a 4-pin round plug-in connector, a 6-post plug-in connector, tube, and fill cup. Depending on your frequency of use, the ice maker may need to be replaced every three to ten years. Regular wear and tear is the main reason this part may need to be replaced but be mindful of accidental damage.
-
Works with the following brandsGeneral Electric, Kenmore, Hotpoint, RCA
-
Works with the following productsRefrigerator, Ice Maker, Freezer, Wine and Beverage Cooler
-
Fixes the following symptomsIce maker not making ice, Ice maker won’t dispense ice, Leaking, Ice maker dispenses too little ice
-
Part Number Cross ReferencePart# WR30X10093 replaces these:AP4345120, 1399596, WR30X10093, 66042, JS-2, JS2, MSE1, WR29X0157, WR29X0158, WR29X0160, WR29X0185, WR29X0191, WR29X10001, WR29X10080, WR29X157, WR29X158, WR29X160, WR29X191, WR29X20949, WR29X27993 ... Show more , WR29X5007, WR29X5012, WR29X5023, WR29X5110, WR29X5114, WR29X5115, WR29X5119, WR29X5121, WR29X5126, WR29X5127, WR29X5130, WR29X5144, WR29X5162, WR29X5167, WR29X5177, WR29X5181, WR29X5183, WR29X5189, WR29X5190, WR30M0149, WR30M0153, WR30M149, WR30M153, WR30X0138, WR30X0147, WR30X0148, WR30X0159, WR30X0169, WR30X0199, WR30X0203, WR30X0213, WR30X0214, WR30X0238, WR30X0241, WR30X0259, WR30X0282, WR30X0283, WR30X0289, WR30X0290, WR30X0304, WR30X0306, WR30X0307, WR30X0315, WR30X0318, WR30X0320, WR30X0327, WR30X0328, WR30X0329, WR30X10012, WR30X10014, WR30X10043, WR30X10044, WR30X10058, WR30X10061, WR30X10082, WR30X10102, WR30X10109, WR30X10111, WR30X10139, WR30X138, WR30X147, WR30X148, WR30X159, WR30X169, WR30X199, WR30X203, WR30X213, WR30X214, WR30X238, WR30X241, WR30X259, WR30X27952, WR30X282, WR30X282R, WR30X283, WR30X28705, WR30X289, WR30X290, WR30X29421, WR30X304, WR30X304R, WR30X306, WR30X307, WR30X315, WR30X318, WR30X320, WR30X327, WR30X328, WR30X329 Show less
Product Description
The ice maker assembly makes ice by filling the tray with water from the inlet valve, freezing it until solid cubes are formed, and then ejecting them into the ice bucket. This process will repeat until the bucket has reached capacity. If your fridge is no longer making ice, the assembly may need to be replaced. This is a genuine OEM replacement that measures 10 inches by 5 inches in size and will make seven crescent shaped pieces of ice each cycle. The kit is mainly made of white plastic, and includes a 4-pin round plug-in connector, a 6-post plug-in connector, tube, and fill cup. Depending on your frequency of use, the ice maker may need to be replaced every three to ten years. Regular wear and tear is the main reason this part may need to be replaced but be mindful of accidental damage.
-
Works with the following brands:General Electric, Kenmore, Hotpoint, RCA
-
Works with the following products:Refrigerator, Ice Maker, Freezer, Wine and Beverage Cooler
-
Fixes the following symptoms:Ice maker not making ice, Ice maker won’t dispense ice, Leaking, Ice maker dispenses too little ice
-
Part# WR30X10093 replaces these:AP4345120, 1399596, WR30X10093, 66042, JS-2, JS2 ... Show more , MSE1, WR29X0157, WR29X0158, WR29X0160, WR29X0185, WR29X0191, WR29X10001, WR29X10080, WR29X157, WR29X158, WR29X160, WR29X191, WR29X20949, WR29X27993, WR29X5007, WR29X5012, WR29X5023, WR29X5110, WR29X5114, WR29X5115, WR29X5119, WR29X5121, WR29X5126, WR29X5127, WR29X5130, WR29X5144, WR29X5162, WR29X5167, WR29X5177, WR29X5181, WR29X5183, WR29X5189, WR29X5190, WR30M0149, WR30M0153, WR30M149, WR30M153, WR30X0138, WR30X0147, WR30X0148, WR30X0159, WR30X0169, WR30X0199, WR30X0203, WR30X0213, WR30X0214, WR30X0238, WR30X0241, WR30X0259, WR30X0282, WR30X0283, WR30X0289, WR30X0290, WR30X0304, WR30X0306, WR30X0307, WR30X0315, WR30X0318, WR30X0320, WR30X0327, WR30X0328, WR30X0329, WR30X10012, WR30X10014, WR30X10043, WR30X10044, WR30X10058, WR30X10061, WR30X10082, WR30X10102, WR30X10109, WR30X10111, WR30X10139, WR30X138, WR30X147, WR30X148, WR30X159, WR30X169, WR30X199, WR30X203, WR30X213, WR30X214, WR30X238, WR30X241, WR30X259, WR30X27952, WR30X282, WR30X282R, WR30X283, WR30X28705, WR30X289, WR30X290, WR30X29421, WR30X304, WR30X304R, WR30X306, WR30X307, WR30X315, WR30X318, WR30X320, WR30X327, WR30X328, WR30X329 Show less
Videos For installing this part.
Replacing your Ice Maker
Questions and Answers
We're sorry, but our Q&A experts are temporarily unavailable.
Please check back later if you still haven't found the answer you need.
- < Prev
- 1
- Next >
Sort by:
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Sorry, we couldn't find any existing answers that matched.
Try using some different or simpler keywords, or submit your new question by using the "Ask a Question" button above!
Try using some different or simpler keywords, or submit your new question by using the "Ask a Question" button above!
Pete
October 4, 2022
No water is being dispensed into ice maker.
For model number MODEL NO. GSH22JFXL WW
Hello Pete, thank you for your question. We have researched your model and found that the issue is probably with the water filter, part number FIX8746144. A clogged and damaged filter can make the ice maker water deprived. If that does not take care of the issue, then the problem is most likely to be related to the water valve, part number FIX16226572. The water valve supplies water to the ice maker. If you require assistance placing an order, please contact customer service. We hope that helps!
1 person found this helpful.
Was this helpful?
Thank you for voting!
Related Parts:
Joan
January 14, 2023
Ice maker makes ice cubes but are dumped into bin frozen together. What is causing this? (is a bottom drawer freezer & see no visible water filter anywhere)
For model number GDE20GSHBRSS
Hello Joan, Thank you for your inquiry. If the refrigerator is not cooling insufficiently it can cause the ice to melt and then clump together. Also when the defrost cycle is activated, it passes heat through the freezer. Sometimes this heat causes the ice to melt and then refreeze, which can cause it to freeze together in clumps. If you add more items into the freezer, it helps deflect the warmth from the defrost cycle from directly hitting the ice. We would recommend first cleaning the ice bin and removing any particles that could be causing ice buildup which can also cause clumping. Make sure the freezer temperature is at 0 degrees or below at all times. Check the temperature sensor, defrost thermostat, and defrost heater with a multimeter. Good luck with your repair.
Was this helpful?
Thank you for voting!
Related Parts:
- < Prev
- 1
- Next >
Installation Instructions Provided by Fix customers like you.
- < Prev
- 1
- 2
- 3
- Next >
Sort by:
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Sorry, we couldn't find any existing installation instruction that matched.
-
Customer:marion from raleigh, NC
-
Parts Used:WR30X10093
-
Difficulty Level:Very Easy
-
Total Repair Time:15 - 30 mins
-
Tools:Screw drivers
Ice maker stopped making ice
Super easy. Loosen 2 screws. Disconnect power line. Take out broken part and plug in new part then slide icemaker back in place and tighten 2 screws. Saved me the $89 service call plus whatever they would have overcharged for the part! And no waiting around for repair guy!
Was this instruction helpful to you?
Thank you for voting!
-
Customer:Diana from Fort Worth, TX
-
Parts Used:WR30X10093
-
Difficulty Level:Very Easy
-
Total Repair Time:15 - 30 mins
-
Tools:Screw drivers
Replace Ice Maker
First I watched the video. Then I removed the lower motor to get to the ice maker plug (3 screws) then loosen the two screws holding the ice maker up and unplugged it and put the new one in. Put motor back in that covered the ice-maker plug and it was a fix. A perfect match even for a refrigerator over 10 years old. Absolutely the easiest fix I have had on any refrigerator. And had i not watched the video i would of never tried this myself. This is the second time I have used your videos and saved myself hundreds of dollars.. Oh by the way I am over 60 years old and a girl.
Was this instruction helpful to you?
Thank you for voting!
-
Customer:Joseph from Mickleton, NJ
-
Parts Used:WR30X10093
-
Difficulty Level:Really Easy
-
Total Repair Time:15 - 30 mins
-
Tools:Nutdriver
Ice not dispensing in GE Profile - water dispensed fine
Ran diagnostic - claws rotated, water filled spout - but no release of cubes. Assume heating element for cube release defective. 1st symptom was ice jam on bottom of icemaker. Tried blow dryer with no success. Replaced ice maker and began dispensing in 90 minutes.
Was this instruction helpful to you?
Thank you for voting!
-
Customer:Kevin from Old Tappan, NJ
-
Parts Used:WR30X10093
-
Difficulty Level:Really Easy
-
Total Repair Time:30 - 60 mins
-
Tools:Screw drivers, Socket set
Ice maker was not making ice
The ice maker is held on by two screws. I backed them out,unplugged the unit and simply reversed the procedure. Piece of cake.!!!!!Initially I thought my original problem, w the old unit, was a frozen water line and not the ice maker as there was no water filling the tray. But once I plugged in the new unit the water started filling the ice tray. PS The swing out arm, pops out, once u plug in the unit.
Was this instruction helpful to you?
Thank you for voting!
-
Customer:Jaaon from Enola, PA
-
Parts Used:WR30X10093
-
Difficulty Level:Really Easy
-
Total Repair Time:Less than 15 mins
-
Tools:Nutdriver
Not making ice
Pulled out old ice maker, with a driver & installed new ice maker. New ice in about 1/2 hr, but full tray in 24 hours.
Was this instruction helpful to you?
Thank you for voting!
-
Customer:MATTHEW from SHELTON, WA
-
Parts Used:WR30X10093
-
Difficulty Level:Very Easy
-
Total Repair Time:Less than 15 mins
-
Tools:Screw drivers
No longer making ice.
Remove ice collection bin. Turned ice maker off. One screw to remove old ice maker. Unplugged wire harness. Removed water fill tray from old ice maker and put on new ice maker. The one that came with new ice maker was smaller than old one. Put in new ice maker with one screw, then plugged in wire harness. Lastly turned on ice maker & replace ice bin.
Was this instruction helpful to you?
Thank you for voting!
-
Customer:Donald from Colleyville, TX
-
Parts Used:WR30X10093
-
Difficulty Level:Easy
-
Total Repair Time:30 - 60 mins
-
Tools:Screw drivers
Ice Maker not working.
Installation was fairly easy following the directions except for 3 items. 1. You are instructed to remove the strippr from the old ice maked and place it on the new one. The old part does not fit. The molded tabs are different. And WHY would you pay for a new ice maker and have to use old parts? 2. The supplied power cord is 8" longer that the original part. it is quite stiff. I finally tie wrapped it inot an accordian to allow the bucket into the freezer. Even so it hang up on the bucket. If anyone else takes the bucket out they will have difficulty properly getting it back in place. 3. LASTLY, since I had questions about items #1 & 2 above I called the "help" number listed throughout the instructions. After getting through I was told there was no help to be had. Call a technician! Don't be dissuaded by my rant. The job is easy. It could be easier if the cord was the proper length BOTTOM LINR- it works!.
Was this instruction helpful to you?
Thank you for voting!
-
Customer:George from Albuquerque, NM
-
Parts Used:WR30X10093
-
Difficulty Level:Very Easy
-
Total Repair Time:Less than 15 mins
-
Tools:Screw drivers
Ice maker not making ice.
Unscrewed 1 screw pulled out and unplugged the old ice maker, placed in the new one put the 1 screw back in, reconnected , turned to on and was done.
Was this instruction helpful to you?
Thank you for voting!
-
Customer:Doug from Mooresville, IN
-
Parts Used:WR30X10093
-
Difficulty Level:Really Easy
-
Total Repair Time:Less than 15 mins
-
Tools:Screw drivers
Needed a new ice maker
The manufacturer changed the model so it wasn't an exact match. But after some repurchase online w/ the model number of the original ice maker. I found that this was the recommended part , pushed a wire out of the way & bingo we have ice.
Was this instruction helpful to you?
Thank you for voting!
-
Customer:George from Springfield, VA
-
Parts Used:WR30X10093
-
Difficulty Level:Really Easy
-
Total Repair Time:30 - 60 mins
-
Tools:Nutdriver, Screw drivers
Ice maker quit working
unplug refrigerator from electricity or turn off circuit breaker that supplies power to the refrigerator. remove and set aside ice tray and top shelf from freezer compartment. unscrew two hex head screws at top of and holding ice maker in freezer just loosen these screws out about a 1/4 inch, do not remove them. remove the screws holding the motor for the ice screw that moves ice out of tray. pull on the motor and just drop it down out of way. now unplug the ice makers electrical plug from back wall of freezer. There are tabs on each side of this plug that you have to pull out at bottom in order to be able to pull plug out. then lift up on ice maker and clear two screws which hold ice maker in. pull ice maker out of Freezer. put new ice maker in freezer by placing the ice maker"s two screw holes over the two hex head screws and pull ice maker down until it won't pull down any further. make sure its level and then tighten screws firmly. plug electric cord into receptical on back of freezer wall make sure you hear it snap and lock into position. Re-align the ice screw motor in place and insert screws and tighten. Replace ice tray making sure fitting on the back of ice tray meshes with the mechanism on the ice screw motor. replace the top shelf of freezer. turn power to refrigerator on then wait until ice starts to fall into tray. may be more than an hour.
Was this instruction helpful to you?
Thank you for voting!
- < Prev
- 1
- 2
- 3
- Next >
★
Customer Reviews
Filter By Rating:
- < Prev
- 1
- Next >
Sort by:
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Sorry, we couldn't find any existing reviews that matched. Try using some different or simpler keywords.
Stephen C - August 19, 2021
Verified Purchase
Ice Maker Replacement
My GE Profile ice maker would only make one batch of ice a day. Looked up on U Tube and found that 93% of ice maker problems needed to replace ice maker. Went online with Fix It and ordered the ice maker needed. Came in about a week and following u tube guide removed old unit and replaced it with the new one in about 15 minutes. My ice maker is now making ice at full capacity and working great. FIX IT was priced fairly and delivered in reasonable time. Great company to work with!!
Lynn N - August 15, 2021
Verified Purchase
Ice maker
Easy install, works great
John M - June 29, 2021
Verified Purchase
Easy fix
Great product and easy to install. Took about 10 min to complete. work up in the morning with a full ice bin and the unit shut off by itself. Great job.
Marques D - February 6, 2021
Verified Purchase
Ice Maker Replacement
The new part fixed the problem and it was a fairly easy fix. 3rd time I've used Fix.com to repair the refrigerator.
- < Prev
- 1
- Next >
Model Compatibility
This part works with the following models:
Fix Number: FIX1993870
Manufacturer Part Number: WR30X10093
Manufacturer Part Number: WR30X10093
Brand
Model Number
Description
