Watch the install video
12741350-4-M-GE-WR60X31522-Evaporator Fan Motor
Part Location Diagram of WR60X31522 GE Evaporator Fan Motor
See part 610 in the diagram
Replacing your General Electric Refrigerator Evaporator Fan Motor
12741350-1-S-GE-WR60X31522-Evaporator Fan Motor 360 view
( Grid squares measure 1x1 inch )
12741350-1-S-GE-WR60X31522-Evaporator Fan Motor 360 view
Part Location Diagram of WR60X31522 GE Evaporator Fan Motor Replacing your General Electric Refrigerator Evaporator Fan Motor

Evaporator Fan Motor WR60X31522

Rated by 18 customers

?

Really Easy

15 - 30 mins

Ratings submitted by customers like you who bought this part.

?
$70.13
In Stock
Fix Number:
FIX12741350
Manufacturer #:
WR60X31522
Manufactured by:
GE

Jump to:

Product Description

This is an evaporator fan motor, located in the freezer compartment. It is sold as a single unit. It is responsible for moving air over the evaporator coils as the compressor is running. When this part is faulty you may hear loud sounds coming from the freezer area, your refrigerator may not stay as cold as normal, or the ice might take longer to freeze. This 115-volt 60Hz evaporator fan motor measures approximately 6.75 inches deep, 3.25 inches wide and 2.5 inches high. Do not forget to disconnect the power to the refrigerator before you begin this repair.

  • Works with the following brands:
    General Electric, Hotpoint
  • Works with the following products:
    Refrigerator, Freezer
  • Fixes the following symptoms:
    Noisy, Fridge too warm, Freezer section too warm, Will Not Start
  • Part# WR60X31522 replaces these:
    WR60X10045, WR60X10046, WR60X10072, WR60X10138, WR60X10141, WR60X10346 , WR60X23584, WR60X27646, WR60X28783, WR60X28784, WR60X31122, WR60X31523 Show less
Works with the following brands:
General Electric, Hotpoint
Works with the following products
Refrigerator, Freezer
Fixes the following symptoms
Noisy, Fridge too warm, Freezer section too warm, Will Not Start
Part Number Cross Reference
Part# WR60X31522 replaces these:
WR60X10045, WR60X10046, WR60X10072, WR60X10138, WR60X10141, WR60X10346, WR60X23584, WR60X27646, WR60X28783, WR60X28784, WR60X31122, WR60X31523

Videos For installing this part.

Replacing your Evaporator Fan Motor

Replacing your Evaporator Fan Motor

Questions and Answers

We're sorry, but our Q&A experts are temporarily unavailable.
Please check back later if you still haven't found the answer you need.

2 questions answered by our experts.
  • 1
Sort by:
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Sorry, we couldn't find any existing answers that matched.
Try using some different or simpler keywords, or submit your new question by using the "Ask a Question" button above!
Ted
October 15, 2021
On this model there are two fans top and bottom, is the motor the same? Is this something the home owner could replace? Thanks
For model number GTS18GTHSRWW
Fix.com logo
Hello Ted, Thank you for the question. The Top fan is the Evaporator Fan, Fix Number: FIX10063450 and the bottom is the Condenser Fan, Fix Number: FIX11721902. The Fan motors are different. Most customers have been able to perform the repair on their own. We hope this helps!

8 people found this helpful.

Was this helpful?
Thank you for voting!
Related Parts:
Condenser Fan Motor
$110.16
In Stock
Nancy
February 21, 2025
Wondering if this part will stop endless noise . Temperatures for freezer and lower fridge are good. But when running it is hours at a time. Sometimes all day or all night. Noise is annoying. Medium level.
For model number GTH17BBZ2LWW
Fix.com logo
Hello Nancy, thank you for your question. Yes, the replacement of the Evaporator Fan Motor PS12741350 should correct the issue with the temperature and the noise. Good luck with your repair.

1 person found this helpful.

Was this helpful?
Thank you for voting!
Evaporator Fan Grommet - Red
$13.16
In Stock
Part Number: FIX963756
The evaporator fan grommet is used to provide a cushion between the fan motor and the motor mounting bracket in your freezer. This genuine OEM part is about one inch in diameter and is red in color. It is part of the mot...
Affresh Washing Machine Cleaner - 3 pack
$12.54
In Stock
Part Number: FIX1960673
This front load washer cleaner removes odor-causing residue. Use it once a month and it will keep your machine fresh and clean. Package comes with 3 tablets.
Affresh Dishwasher Cleaner Tablets - 6
$19.04
In Stock
Part Number: FIX12345667
Affresh dishwasher Cleaner is specially formulated to help remove limescale and mineral build-up that can be unsightly and could affect your dishwasher's performance. Each tablet is designed to clean inside your machine ...
Produce Preserver Filter
$21.44
In Stock
Part Number: FIX3503014
Fresh Flow Produce Preserver is made for your refrigerator to help keep produce fresh for longer by absorbing the chemical, ethylene, that causes your fruits and vegetables to ripen quicker. Your produce could be fresh f...
Affresh Washing Machine Cleaner Tablets – 6 Count
$21.08
In Stock
Part Number: FIX12345661
This Affresh Washing Machine Cleaner deep cleans to help remove the odor-causing residues and grime that daily loads leave behind. The time-release tablets are EPA Safer Choice certified, septic-safe and designed to clea...
Cooktop Cleaner
$17.69
In Stock
Part Number: FIX3492527
Affresh® Dishwasher Cleaner is the #1 recommended cleaner by Whirlpool, KitchenAid, and Maytag brands, designed to remove limescale and mineral build-up that can affect your dishwasher’s performance. These powerful table...
Refrigerator Deodorizer
$19.17
In Stock
Part Number: FIX12739141
Refrigerator deodorizers help to reduce bacteria growth and therefore reduce smells and extend the life of food.
View More View Less
Evaporator Fan Grommet - Red
$13.16
In Stock
Part Number: FIX963756
Affresh Washing Machine Cleaner - 3 pack
$12.54
In Stock
Part Number: FIX1960673
Affresh Dishwasher Cleaner Tablets - 6
$19.04
In Stock
Part Number: FIX12345667
Produce Preserver Filter
$21.44
In Stock
Part Number: FIX3503014
Affresh Washing Machine Cleaner Tablets – 6 Count
$21.08
In Stock
Part Number: FIX12345661
Cooktop Cleaner
$17.69
In Stock
Part Number: FIX3492527
Refrigerator Deodorizer
$19.17
In Stock
Part Number: FIX12739141

Installation Instructions Provided by Fix customers like you.

Average Repair Rating: 4.1 / 5.0, 18 reviews.
  • 1
  • 2
Sort by:
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Sorry, we couldn't find any existing installation instruction that matched.
Customer:
Francis from Rochester, NY
Parts Used:
WR60X31522
Difficulty Level:
Very Easy
Total Repair Time:
15 - 30 mins
Tools:
Nutdriver, Screw drivers
Noisey fan
Unplug power, remove several parts to access the fan motor located at the back of the freezer section. Disconnect fan motor. Remove impeller from motor shaft. Reassemble all parts. Very easy repair.
6 of 6 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Customer:
Richard from Hilliard, OH
Parts Used:
WR60X31522, WR02X12008, WR02X10540
Difficulty Level:
Really Easy
Total Repair Time:
30 - 60 mins
Tools:
Nutdriver, Pliers, Screw drivers
Noisy Freezer
Removed all content of freezer. Unplugged refrigerator. Removed ice rack and back deflector panel including Styrofoam piece. Removed freezer back panel. All simple push and pull or screw attachments. Unplugged motor connector and ground wire. Removed fan bracket with nut driver. Unit was then removed from freezer to conduct replac ements. Removed fan blade (simple ring clip and pull off of motor shaft. Replaced items in bracket (required nut driver). Reinstalled all items. First time fix and worked slowly because of unfamiliar with the process. Total start to finish was less than an hour.
Read less
3 of 4 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Customer:
Paul from Collinwood, TN
Parts Used:
WR60X31522, WR55X24064
Difficulty Level:
Really Easy
Total Repair Time:
30 - 60 mins
Tools:
Screw drivers, Wrench (Adjustable), Wrench set
Refrigerator Not Cooling
1) Run Capacitor. Disconnected electrical power plug from the wall socket. Located the Run Capacitor in bottom rear of refrigerator, disconnected the retainer spring, pulled the wasted run capacitor off and plugged the new one into the slot and replaced the retainer spring. 2) Motor AC/DC Evaporator Fan. Opened top freezer door. Removed t he shelving by carefully sliding the shelving pins upward and into the recessed slots for easy removal. Used Phillip's head screw driver to remove two screws holding the face guard in place and the 6" Crescent wrench to remove the bracket holding the fan motor to the bracket and the Phillip's head screw driver to remove two screws holding the bracket to the inside rear of the freezer. Unplugged the wasted motor AC/DC Evaporator Fan and plugged the new one into its place. Reinstalled all hardware as it came out. Refrigerator is now working like new. Simple and easy project saved me $100s of dollars fro having to purchase a new Refrigerator. My significant other was happy that it worked so well and saved $$. She was happy and went to Walmart shopping with the savings and brought me a pizza home. Everyone was a winner. Paul and Kimberly Juliana
Read less
2 of 2 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Customer:
Mark from Myrtle Beach, SC
Parts Used:
WR60X31522
Difficulty Level:
Easy
Total Repair Time:
15 - 30 mins
Tools:
Nutdriver, Screw drivers
Noisy Fan Motor in Freezer
Removed two panels - Removed motor and fan assy-swapped fan blade to new motor - replaced assy and panels
2 of 3 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Customer:
Kenneth from SAN ANTONIO, TX
Parts Used:
WR60X31522, WR60X10204, WR02X12008
Difficulty Level:
Easy
Total Repair Time:
30 - 60 mins
Tools:
Screw drivers, Wrench (Adjustable)
Freezer cold, refrigerator not cold
The biggest challenge was removing the plastic cover to the evaporator. Replacing the evaporator was straightforward. I watched YouTube’s ahead of this repair - quite helpful.

Here’s the one big watch out: make sure when you attach the evaporator fan to the evaporator motor that it blows the air down into the refrigerator and n ot into the freezer.

If you find the evaporator fan is blowing the air into the freezer compartment, then carefully remove the evaporator fan from the evaporator motor, turn it over and re-attach it again. It should blow the air into the refrigerator at this point.

Finish reassembly and you are good to go.
Read less
1 person found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Customer:
Joseph from Midland, TX
Parts Used:
WR60X31522, WR60X10204, WR02X12008
Difficulty Level:
Really Easy
Total Repair Time:
15 - 30 mins
Tools:
Nutdriver, Pliers, Screw drivers
Very Noisy Intermitent Evaporator Fan
I just followed the "how to" videos which were very helpful with one exception. I turned off the circuit breaker in the garage rather than pull the fridge out from the wall to unplug it which was easier. This also eliminated the need to raise the leveling feet so the rollers would touch the floor for a pull out. I replaced the grommets and the fan blade as well but really didn't need to as the motor was the culprit. Works like new now and an expensive service call was avoided.
Read less
1 person found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Customer:
Kenneth from Elkhorn City, KY
Parts Used:
WR60X31522, WR50X10071
Difficulty Level:
A Bit Difficult
Total Repair Time:
15 - 30 mins
Tools:
Nutdriver, Pliers, Screw drivers
Fan noisy and water leaking down into fridge
Removed interior freezer panels. Changed motor and thermostat. Good as new
1 person found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Customer:
georgia from Libby, MT
Parts Used:
WR60X10204, WR60X31522, WR02X12008
Difficulty Level:
Really Easy
Total Repair Time:
Less than 15 mins
Tools:
Screw drivers, Socket set
freezer fan extremely loud, knocking-AAAAGH!!!!
Unplug fridge. remove center piece, 2 screws. Remove 2 screws from icemaker, slide it foreward. Pull styrofoam out of centerpiece. Remove 2 screws from back and take it out. Remove 2 screws from fan assembly and unplug power and ground wire. Pull fan, motor and old grommets out and pitch it. Put new stuff in replugging and rescrewin g in reverse order. Enjoy the quiet!
Read less
1 person found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Customer:
joe from salem, AR
Parts Used:
WR60X31522
Difficulty Level:
Very Easy
Total Repair Time:
15 - 30 mins
Tools:
Nutdriver, Screw drivers
making noise
very easy to fix. justwatch the repair movie
0 of 1 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Customer:
Deborah from Davenport, IA
Parts Used:
WR60X31522
Difficulty Level:
Really Easy
Total Repair Time:
30 - 60 mins
Fan motor not working in freezer
I removed broken motor. Took off fan blade from old motor and put it on the new motor and installed the new motor.
0 of 1 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
  • 1
  • 2

Model Compatibility

This part works with the following models:
Fix Number: FIX12741350
Manufacturer Part Number: WR60X31522
Brand
Model Number
Description
General Electric
36211XBMBRWW
Refrigerator
General Electric
36211XBMDRWW
Refrigerator
General Electric
36211XBMERWW
General Electric
36211XBMFRWW
General Electric
36211XBRERWW
General Electric
36211XBRFRWW
General Electric
36411XBRERWW
Refrigerator
General Electric
36411XBRFRWW
Refrigerator
General Electric
37511KBSARWW
Refrigerator
General Electric
37511KBSERWW
Refrigerator
General Electric
38341FBMERWW
General Electric
38341FBMFRWW
Refrigerator
General Electric
38351HBMERWW
General Electric
38351HBMFRWW
Refrigerator
General Electric
38351HBRERWW
General Electric
38351HBRFRWW
General Electric
38451HBRERWW
Refrigerator
General Electric
38451HBRFRWW
Refrigerator
General Electric
A3315ABRERWW
Refrigerator
General Electric
A3315ABRFRWW
Refrigerator
General Electric
A3315ABRW
Refrigerator - GE Refrigerator Model A3315ABRW Parts
General Electric
A3316ABSARBB
Refrigerator
General Electric
A3316ABSARWW
Refrigerator
General Electric
A3316ABSB
Refrigerator - GE Refrigerator Model A3316ABSB Parts
General Electric
A3316ABSBRBB
Refrigerator
General Electric
A3316ABSBRWW
Refrigerator
General Electric
A3316ABSERBB
Refrigerator
General Electric
A3316ABSERWW
Refrigerator
General Electric
A3316ABSW
Refrigerator - GE Refrigerator Model A3316ABSW Parts
General Electric
A3317ABRERWW
Refrigerator
