Watch the install video
236043-1-M-GE-WB21X5301 -Oven Sensor
Part Location Diagram of WB21X5301 GE Oven Sensor
See part 253 in the diagram
Replacing your General Electric Range Oven Sensor
236043-1-S-GE-WB21X5301 -Oven Sensor 360 view
( Grid squares measure 1x1 inch )
236043-1-S-GE-WB21X5301 -Oven Sensor 236043-2-S-GE-WB21X5301 -Oven Sensor 236043-1-S-GE-WB21X5301 -Oven Sensor 360 view
Part Location Diagram of WB21X5301 GE Oven Sensor Replacing your General Electric Range Oven Sensor

Oven Sensor WB21X5301

Works With Model RGB745WEH3WW!

Rated by 6 customers

?

Really Easy

30 - 60 mins

Ratings submitted by customers like you who bought this part.

?
$50.80
In Stock
Fix Number:
FIX236043
Manufacturer #:
WB21X5301
Manufactured by:
GE
Works With Model RGB745WEH3WW!

Jump to:

Product Description

This sensor detects the temperature within the oven cavity.

  • Works with the following brands:
    General Electric, Kenmore, Hotpoint, Whirlpool
  • Works with the following products:
    Range, Wall Oven, Microwave Oven Combo
  • Fixes the following symptoms:
    Little to no heat when baking, Oven not heating evenly, Oven is too hot, Will Not Start
  • Part# WB21X5301 replaces these:
    AP2023670, 252618, WB21X5301, 334300, 347163, 347183 , 4337170, 65939, WB20K4, WB20X106, WB21X5263, WB21X5275, WB21X5296, WB21X5318, WB21X5321, WB21X5347, WB8K5007 Show less
Works with the following brands:
General Electric, Kenmore, Hotpoint, Whirlpool
Works with the following products
Range, Wall Oven, Microwave Oven Combo
Fixes the following symptoms
Little to no heat when baking, Oven not heating evenly, Oven is too hot, Will Not Start
Part Number Cross Reference
Part# WB21X5301 replaces these:
AP2023670, 252618, WB21X5301, 334300, 347163, 347183, 4337170, 65939, WB20K4, WB20X106, WB21X5263, WB21X5275, WB21X5296, WB21X5318, WB21X5321, WB21X5347, WB8K5007

Videos For installing this part.

Replacing your Oven Sensor

Replacing your Oven Sensor

Questions and Answers

Be the first to ask our experts a question about this part!

Affresh Washing Machine Cleaner - 3 pack
$12.54
In Stock
Part Number: FIX1960673
This front load washer cleaner removes odor-causing residue. Use it once a month and it will keep your machine fresh and clean. Package comes with 3 tablets.
Affresh Dishwasher Cleaner Tablets - 6
$19.04
In Stock
Part Number: FIX12345667
Affresh dishwasher Cleaner is specially formulated to help remove limescale and mineral build-up that can be unsightly and could affect your dishwasher's performance. Each tablet is designed to clean inside your machine ...
Produce Preserver Filter
$21.44
In Stock
Part Number: FIX3503014
Fresh Flow Produce Preserver is made for your refrigerator to help keep produce fresh for longer by absorbing the chemical, ethylene, that causes your fruits and vegetables to ripen quicker. Your produce could be fresh f...
Affresh Washing Machine Cleaner Tablets – 6 Count
$21.08
In Stock
Part Number: FIX12345661
This Affresh Washing Machine Cleaner deep cleans to help remove the odor-causing residues and grime that daily loads leave behind. The time-release tablets are EPA Safer Choice certified, septic-safe and designed to clea...
Cooktop Cleaner
$17.69
In Stock
Part Number: FIX3492527
Affresh® Dishwasher Cleaner is the #1 recommended cleaner by Whirlpool, KitchenAid, and Maytag brands, designed to remove limescale and mineral build-up that can affect your dishwasher’s performance. These powerful table...
Refrigerator Deodorizer
$19.17
In Stock
Part Number: FIX12739141
Refrigerator deodorizers help to reduce bacteria growth and therefore reduce smells and extend the life of food.
Affresh Washing Machine Cleaner - 3 pack
$12.54
In Stock
Part Number: FIX1960673
Affresh Dishwasher Cleaner Tablets - 6
$19.04
In Stock
Part Number: FIX12345667
Produce Preserver Filter
$21.44
In Stock
Part Number: FIX3503014
Affresh Washing Machine Cleaner Tablets – 6 Count
$21.08
In Stock
Part Number: FIX12345661
Cooktop Cleaner
$17.69
In Stock
Part Number: FIX3492527
Refrigerator Deodorizer
$19.17
In Stock
Part Number: FIX12739141

Installation Instructions Provided by Fix customers like you.

Average Repair Rating: 3.9 / 5.0, 6 reviews.
  • 1
Sort by:
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Sorry, we couldn't find any existing installation instruction that matched.
Customer:
Timothy from Gurnee, IL
Parts Used:
WB21X5301
Difficulty Level:
Easy
Total Repair Time:
30 - 60 mins
Tools:
Nutdriver, Pliers, Screw drivers
F2 Error - Temp Probe Failed
Watched a U-Tube video and it went just like the video. Clear stove of racks etc. Move stove away from wall, unplug electric, remove access cover on back of stove. Remove old probe. Snap together fitting did not match. Slip new probe wires through insulated access hole. Clip and strip all wires. Wire nut probe wires to range wires with insulated nuts provided. Replace access cover. Slide stove back. The fix went fast. Moving the stove and getting in and out from behind it and cleaning under it (the floor and back/side walls since no one ever moves it to clean there) took far longer than replacing the probe.
Read less
2 of 2 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Customer:
Joel from Mukwonago, WI
Parts Used:
WB2X9154, WB21X5301
Difficulty Level:
Really Easy
Total Repair Time:
30 - 60 mins
Tools:
Nutdriver, Screw drivers, Socket set
Oven would not lite or turn on. Temp control was off buy more than 50 degrees
I followed the instructions given and removed the igniter and replaced it with the new one. It was not hard at all.the temp control was even simpler. I have ms.and if I could do it. Anyone can.the oven now works like new. The cost to repair was low compared to a new stove.i ordered the parts and received them the next day, outstanding.
1 person found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Customer:
edward from Southington, CT
Parts Used:
WB21X5301
Difficulty Level:
Really Easy
Total Repair Time:
30 - 60 mins
Tools:
Nutdriver, Pliers
code f2. oven shut off
Filled directions given with part. Worked perfect!!!
1 person found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Customer:
Stephen from Rancho Cucamonga, CA
Parts Used:
WB21X5301
Difficulty Level:
Really Easy
Total Repair Time:
30 - 60 mins
Tools:
Pliers, Screw drivers
F2 code on display
Built in self cleaning oven. Removed racks,drawers and door. Set oven on 2 chairs with 2x4s for height. Removed the back panel and saw the wire nuts. Removed the connector plug and cut the wire on the old sensor. Duct taped the new sensor wires together and pushed through. Connected new sensor and closed the box. Oven is back on without the f2.
Read less
0 of 1 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Customer:
Jeff from Hendersonville, TN
Parts Used:
WB21X5301
Difficulty Level:
Really Easy
Total Repair Time:
15 - 30 mins
Tools:
Pliers, Screw drivers, Socket set
Oven sensor failure, temps would swing from high to low
FIRST I disconnected the power, then I pulled the oven from the wall. I took the back off of the oven, removed the two screws from the inside holding the sensor in place, cut the wires on the back, pulled them thru when I removed the sensor, then fed the new wires through the back in the oven and reconnected as shown on the repair instruc tions with the ceramic nuts making sure they didnt touch the back of the cabinet. Then I pushed the insulation back around the wires, put the back on it, reinstalled in the wall, and turned the power back on--works like it did when it was new
Read less
0 of 1 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Customer:
Mark from Casa Grande, AZ
Parts Used:
WB21X5301
Difficulty Level:
Really Easy
Total Repair Time:
15 - 30 mins
Tools:
Nutdriver, Screw drivers
Oven temperature was a minimum of 50 degrees off - cooler
The heat sensor was a direct replacement of the old sensor. I taped a piece of string on the old plug before removing the old sensor, I was able to easily pull the new wire/plug through the insulation and to the back of the stove.
0 of 1 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
  • 1

Model Compatibility

This part works with the following models:
Fix Number: FIX236043
Manufacturer Part Number: WB21X5301
Brand
Model Number
Description
Kenmore
1034688610
Range
General Electric
10451-1
Range
General Electric
10451-2
Range
General Electric
10451-3
Range
General Electric
10461-1
Range
General Electric
10461-2
Range
General Electric
10461-3
Range
General Electric
10470-1
Range
General Electric
10470-2
Range
General Electric
10470-3
Range
General Electric
10471-1
Range
General Electric
10471-2
Range
General Electric
10471-3
Range
General Electric
10477-1
Range
General Electric
10477-2
Range
General Electric
10478-1
Range
General Electric
10478-2
Range
General Electric
10481-1
Range
General Electric
10481-2
Range
General Electric
10481-3
Range
General Electric
10551-1
Range
General Electric
10551-2
Range
General Electric
10551-3
Range
General Electric
10561-1
Range
General Electric
10561-2
Range
General Electric
10561-3
Range
General Electric
10570-1
Range
General Electric
10570-2
Range
General Electric
10570-3
Range
General Electric
10571-1
Range
