Thumb Screw - Black
Works With Model KV25G0XIC5!
$23.40
In Stock
Fix Number: FIX11747009
Manufacturer #: WP9709194
Manufactured by:
Whirlpool
Works With Model KV25G0XIC5!
-
Product Description
This part is used with the stand mixers attachments, as well as to hold the end cap to the front of the mixer.
-
Works with the following brandsKitchenAid, Whirlpool
-
Works with the following productsMixer
-
Fixes the following symptomsTouchpad does not respond
-
Part Number Cross ReferencePart# WP9709194 replaces these:AP6013782, 240374, 240374-3, 4162142, 4169829, 9709194, 9709198
Product Description
This part is used with the stand mixers attachments, as well as to hold the end cap to the front of the mixer.
-
Works with the following brands:KitchenAid, Whirlpool
-
Works with the following products:Mixer
-
Fixes the following symptoms:Touchpad does not respond
-
Part# WP9709194 replaces these:AP6013782, 240374, 240374-3, 4162142, 4169829, 9709194 ... Show more , 9709198 Show less
Videos For installing this part.
Replacing your Thumb Screw - Black
Questions and Answers
We're sorry, but our Q&A experts are temporarily unavailable.
Please check back later if you still haven't found the answer you need.
Related PartsAdditional or alternate parts to consider.
Installation Instructions Provided by Fix customers like you.
- < Prev
- 1
- Next >
Sort by:
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Sorry, we couldn't find any existing installation instruction that matched.
-
Customer:Jeffery from Omega, GA
-
Difficulty Level:Really Easy
-
Total Repair Time:30 - 60 mins
-
Tools:Screw drivers
worm gear had worn the teeth down where the mixer would not turn anymore
Removed the band around the end near where the beaters go, then remove the 4 screws holding the case together, then removed the screw holding the end cap over the motor area, then removed 6 screws from near the beaters area. Next, pulled the case apart to get to the worm gear. Remove 3 screws from the worm gear case, then took a hammer an punch and punched the pin holding the worm gear assembly together out, removed the worm gear and replaced and then did all the first steps in reverse order.
Was this instruction helpful to you?
Thank you for voting!
-
Customer:Rose from Oakhurst, TX
-
Difficulty Level:Really Easy
-
Total Repair Time:15 - 30 mins
-
Tools:Pliers
speed control knob, Thumb screw
Husband pull knob from part sent used plumbers tape to make it stay on. the thumb screw he took old one off and put new on.
Was this instruction helpful to you?
Thank you for voting!
-
Customer:Dennis from Ankeny, IA
-
Parts Used:WP9709194
-
Difficulty Level:Very Easy
-
Total Repair Time:Less than 15 mins
-
Tools:Pliers
Plastic knob had broken off of the set screw.
Used pliers to loosen the set screw and removed with fingers. Replaced with new one. Just snugged up. Easy repair
Was this instruction helpful to you?
Thank you for voting!
-
Customer:Michael from Fremont, CA
-
Difficulty Level:Easy
-
Total Repair Time:30 - 60 mins
-
Tools:Pliers, Screw drivers
Accessory input port striped. Not driving attachment.
Problem found is plastic transmission cover cracked causing too much play between gears causing them to skip and strip. New replacement cover is cast metal. Great improvement. Remove trim ring (one screw). Remove top cover (4 screws). Remove plastic transmission cover (4 screws). Remove snap ring that holds too beveled gear. Replace gear and re install snap ring. Replace gear in transmission (other beveled gear) I also replace bronze bushings at each end of the adjacent worm gear. Re pack all gears and transmission cover with fresh grease. Reinstall all gears and transmission cover. Ensure all components are properly seated and lined up. Re instal cover and trim ring. Easy fix. Less than an hour. Works as good as new. Replacement parts fit perfectly.
Was this instruction helpful to you?
Thank you for voting!
