High Limit Thermostat WP661566

Rated by 1 customers

?

Easy

30 - 60 mins

Ratings submitted by customers like you who bought this part.

?
$20.63
In Stock
Fix Number:
FIX11743423
Manufacturer #:
WP661566
Manufactured by:
Whirlpool

Jump to:

Product Description

This part acts as as safety mechanism that keeps the dryer from overheating. Once the dryer temperature reaches a certain point, this part will shut down power to the heating element.

  • Works with the following brands:
    Kenmore, Whirlpool, KitchenAid, Maytag
  • Works with the following products:
    Dishwasher
  • Fixes the following symptoms:
    Not drying dishes properly, Will Not Start, Not cleaning dishes properly
  • Part# WP661566 replaces these:
    AP6010246, 3369777, 3370783, 3371618, 4171694, 661566 , W10339474, WP661566VP Show less
Works with the following brands:
Kenmore, Whirlpool, KitchenAid, Maytag
Works with the following products
Dishwasher
Fixes the following symptoms
Not drying dishes properly, Will Not Start, Not cleaning dishes properly
Part Number Cross Reference
Part# WP661566 replaces these:
AP6010246, 3369777, 3370783, 3371618, 4171694, 661566, W10339474, WP661566VP
