Detergent Dispenser with Rinse Cap
Works With Model 4070600!
$84.00
In Stock
Fix Number: FIX958966
Manufacturer #: WD12X10163
Manufactured by:
GE
Works With Model 4070600!
-
Product Description
This part releases the detergent and rinse aid into the dishwasher.
-
Works with the following brandsGeneral Electric, Hotpoint
-
Works with the following productsDishwasher
-
Fixes the following symptomsWill not dispense detergent, Door latch failure, Not cleaning dishes properly, Door won’t close
-
Part Number Cross ReferencePart# WD12X10163 replaces these:AP3767572, 1055139, WD12X10046, WD12X10112, WD12X10162, WD12X10196, WD12X10205, WD12X10207, WD12X10237, WD12X10239, WD12X10240, WD12X10241
Product Description
This part releases the detergent and rinse aid into the dishwasher.
-
Works with the following brands:General Electric, Hotpoint
-
Works with the following products:Dishwasher
-
Fixes the following symptoms:Will not dispense detergent, Door latch failure, Not cleaning dishes properly, Door won’t close
-
Part# WD12X10163 replaces these:AP3767572, 1055139, WD12X10046, WD12X10112, WD12X10162, WD12X10196 ... Show more , WD12X10205, WD12X10207, WD12X10237, WD12X10239, WD12X10240, WD12X10241 Show less
Videos For installing this part.
Replacing your Detergent Dispenser with Rinse Cap
Questions and Answers
We're sorry, but our Q&A experts are temporarily unavailable.
Please check back later if you still haven't found the answer you need.
Installation Instructions Provided by Fix customers like you.
- < Prev
- 1
- Next >
Sort by:
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Sorry, we couldn't find any existing installation instruction that matched.
-
Customer:Jo-Ann from Reading, PA
-
Parts Used:WD12X10163
-
Difficulty Level:Really Easy
-
Total Repair Time:Less than 15 mins
-
Tools:Screw drivers, Wrench (Adjustable)
detgerent was seeping from warped despenser
followed the video
Was this instruction helpful to you?
Thank you for voting!
-
Customer:Robert from North Ridgeville, OH
-
Parts Used:WD12X10163
-
Difficulty Level:Very Easy
-
Total Repair Time:Less than 15 mins
-
Tools:Screw drivers
The detergent dispenser would not close
The video was excellent and made the job a snap. I turned off the electricity off at 3:33pm,followed the instructions which explained everything,and electricity back on at 3:41pm.
Was this instruction helpful to you?
Thank you for voting!
-
Customer:Neil from Oro Valley, AZ
-
Parts Used:WD12X10163
-
Difficulty Level:Really Easy
-
Total Repair Time:15 - 30 mins
-
Tools:Screw drivers
Detergent dispenser flap latch would not latch
Remove inner door panel. Remove and replace dispenser unit. Reassemble inter door panel.... It helps if you tape the dispenser in place from the inside of the door panel so that you can properly place the retainer brackets and start the screws. I also put a small amount of plumbers valve grease on the dispenser seal just to prevent leaks. If you have one, use a screw gun as there are a bunch of screws to remove/reinstall.
Was this instruction helpful to you?
Thank you for voting!
-
Customer:Roy from Mableton, GA
-
Parts Used:WD12X10163
-
Difficulty Level:Very Easy
-
Total Repair Time:30 - 60 mins
-
Tools:Pliers, Screw drivers
soap dispenser not dispensering
watch video
Was this instruction helpful to you?
Thank you for voting!
-
Customer:Robin from Santa Rosa beach, FL
-
Parts Used:WD12X10163
-
Difficulty Level:Really Easy
-
Total Repair Time:15 - 30 mins
-
Tools:Screw drivers
Dispenser door wouldn't lock
i watched the instructional video once, then watched it again and paused as needed. I've never attempted to fix anything before!
Was this instruction helpful to you?
Thank you for voting!
-
Customer:Glenn from Holly Springs, NC
-
Parts Used:WD12X10163
-
Difficulty Level:Very Easy
-
Total Repair Time:Less than 15 mins
-
Tools:Screw drivers
soap despenser would not release door
Used video instruction on utube
Was this instruction helpful to you?
Thank you for voting!
-
Customer:Gregory from Warrenton, VA
-
Parts Used:WD12X10163
-
Difficulty Level:Easy
-
Total Repair Time:30 - 60 mins
-
Tools:Pliers, Screw drivers
The detergent dispenser was not properly functioning
I removed the screws holding the door together. Then I was able to remove the electrical connections with a pair of pliers. Then I was able to remove the 6 screws that held the dispenser in place. I installed the new dispenser easily and reassembled the door in reverse order based on how I took it apart.
Was this instruction helpful to you?
Thank you for voting!
-
Customer:Michael from Cincinnati, OH
-
Parts Used:WD12X10163
-
Difficulty Level:A Bit Difficult
-
Total Repair Time:30 - 60 mins
-
Tools:Pliers, Screw drivers
Dispenser door catch broken
Followed your video installation recommendations taking care not to overtighten dispenser mounting screws. It leaked! Took apart again, lightly coated o-ring with silicone grease and made fasteners slightly tighter. Reassembled door and all is well.
Was this instruction helpful to you?
Thank you for voting!
-
Customer:Sheri from Boston, MA
-
Parts Used:WD12X10163
-
Difficulty Level:Easy
-
Total Repair Time:Less than 15 mins
-
Tools:Pliers, Screw drivers
the dispenser would not lock when closed
we watched the video on your web site. first we turned off the power to the dishwasher. Then we removed all the screws on the door - gently lowered the frame/door down. we disconnected the control panel and set aside. we then removed the screws around the dispenser, popped the old one out and the new one - put screws back in - reattached the control panel - then reattached back to front door panel. turned power back and all fixed. the video was perfect!
Was this instruction helpful to you?
Thank you for voting!
-
Customer:Scott from Blair, NE
-
Parts Used:WD12X10163
-
Difficulty Level:Really Easy
-
Total Repair Time:Less than 15 mins
-
Tools:Screw drivers
Lock Clip was broke on soap dispenser
Watched the video which made it so easy. Thanks!
Was this instruction helpful to you?
Thank you for voting!
