High Limit Thermostat

Rated by 1 customers

?

Easy

30 - 60 mins

Ratings submitted by customers like you who bought this part.

?
$57.45
In Stock
Fix Number: FIX420575
Manufacturer #: 154290204
Manufactured by: Frigidaire
  • Product Description

    This resettable hi-limit thermostat acts as a safety mechanism that keeps the dishwasher from overheating. This part will cut out if the internal temperature reaches 200 degrees Fahrenheit. It will reset when the temperature drops to 100 degrees Fahrenheit - the differential of 100 degrees.

  • Works with the following brands
    Frigidaire, Kenmore, Gibson, Crosley
  • Works with the following products
    Dishwasher
  • Fixes the following symptoms
    Not drying dishes properly, Not cleaning dishes properly
  • Part Number Cross Reference
    Part# 154290204 replaces these:
    AP2109201, 12758, 154290201, 154290202, 154290203
1 Installation Video Questions and Answers
1 Installation Instruction Model Compatibility
Product Description Part Videos Questions and Answers Installation Instructions Model Compatibility

Product Description

This resettable hi-limit thermostat acts as a safety mechanism that keeps the dishwasher from overheating. This part will cut out if the internal temperature reaches 200 degrees Fahrenheit. It will reset when the temperature drops to 100 degrees Fahrenheit - the differential of 100 degrees.

  • Works with the following brands:
    Frigidaire, Kenmore, Gibson, Crosley
  • Works with the following products:
    Dishwasher
  • Fixes the following symptoms:
    Not drying dishes properly, Not cleaning dishes properly
  • Part# 154290204 replaces these:
    AP2109201, 12758, 154290201, 154290202, 154290203

Videos For installing this part.

Replacing your High Limit Thermostat

Replacing your High Limit Thermostat

Questions and Answers

We're sorry, but our Q&A experts are temporarily unavailable.
Please check back later if you still haven't found the answer you need.

Installation Instructions Provided by Fix customers like you.

Average Repair Rating: 3.3 / 5.0, 1 reviews.
  • 1
Sort by:
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Sorry, we couldn't find any existing installation instruction that matched.
  • Customer:
    Danny from ATASCADERO, CA
  • Parts Used:
    154665201, 154290204
  • Difficulty Level:
    Easy
  • Total Repair Time:
    30 - 60 mins
  • Tools:
    Nutdriver, Pliers, Screw drivers, Wrench set
Dishes not drying, not cleaning properly
Removed the bottom front cover. removed the screws holding the water valve and moved it out of the way. Located the thermostat and connections for heating element. Loosen the thermostat retainer with short Phillips screwdriver. Remove thermostat. One connection was burnt, cut to good wire, crimped on new connector. installed new thermostat reverse of removal. Removed wire connectors for heating element, loosened brass nuts with short 13mmbox wrench(1/2" will fit). not much room for big tools. Removed element from inside washer. Installed new element reverse of removal. Washer works like new.
