Part Location Diagram of WP7403P876-60 Whirlpool Vent Fan Control Switch
See part 16 in the diagram
( Grid squares measure 1x1 inch )

Vent Fan Control Switch WP7403P876-60

Works With Model CVGX2423B!

Rated by 1 customers

?

Really Easy

15 - 30 mins

Ratings submitted by customers like you who bought this part.

?
$142.21
In Stock
Fix Number:
FIX11744497
Manufacturer #:
WP7403P876-60
Manufactured by:
Whirlpool
Works With Model CVGX2423B!

Product Description

Downdraft vent fan control switch activates and controls the speed of the downdraft fan motor in the cooktop.

Questions and Answers

We're sorry, but our Q&A experts are temporarily unavailable.
Please check back later if you still haven't found the answer you need.

View More View Less
KNOB,FAN BLACK
$25.30
No Longer Available
Affresh Washing Machine Cleaner - 3 pack
$12.58
In Stock
Produce Preserver Filter
$21.50
In Stock
Affresh Dishwasher Cleaner Tablets - 6
$19.09
In Stock
Cooktop Cleaning Cream
$15.57
In Stock
Cooktop Cleaner
$17.74
In Stock
Affresh Cleaner
$19.09
In Stock

Installation Instructions Provided by Fix customers like you.

Average Repair Rating: 4.4 / 5.0, 1 reviews.
  • 1
Sort by:
Sorry, we couldn't find any existing installation instruction that matched.
Customer:
Cyndy K. from Virginia Beach, VA
Parts Used:
WP7403P876-60, Y706103, W11715914
Difficulty Level:
Really Easy
Total Repair Time:
15 - 30 mins
Tools:
Screw drivers
Broke off knob stem and all!
First turn off power to unit and the gas. This was very easy. Used a screwdriver to remove the screws on the side I believe there were 4 of them. Removed all knobs for the gas. Lift up glass part carefully remove 2 screws on metal plate. Remove the nut on top of the fan switch and save. You will need to reuse. The switch did n ot match the one I have but it worked perfectly. Remove the metal clips from old switch and put on new switch. I turned power back on while still apart just to be sure it worked. Then I just reversed everything I did. Just be sure that you put the knob on before you put everything back to be sure how to attach switch on plate. I did it backwards the first try. This was a very easy thing to do. Sure saved me a lot of money. What really took me the longest was cleaning under the knobs while I was working. I had never removed the knobs and cleaned under them. I recommend you do this often!
0 of 1 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
  • 1

Model Compatibility

This part works with the following models:
Fix Number: FIX11744497
Manufacturer Part Number: WP7403P876-60
Brand
Model Number
Description
Jenn-Air
CVGX2423B
Cooktop - Gas
Jenn-Air
CVGX2423B18
Cooktop - 34" GAS BUILT-IN DOWNDRAFT COOKTOP
Jenn-Air
CVGX2423Q
Cooktop - Gas
Jenn-Air
CVGX2423W
Cooktop - Gas
